Wisdom Cym0609 Wood Cnc Router Milling Machine 300 X 900 Mm

US $5,588.00

San Francisco, California, United States
Jan 30th

Open on mobile:
QR code

Wisdom CYM0609 Wood CNC Router Milling Machine Features: Z Travel is 4 inches/100mm The column is adjustable up and down by loosing 4 cap screws, giving more table clearance if needed. Up to 4 inches/100mm of clearance under the collet. The CYG0609 comes standard with a 6mm collet. ER16 Collet system will adapt to this machine and can be purchased from independent dealers. Specifications: X,Y,Z Working Area 600x900x120mm Table Size 1560X1050mm X,Y,Z Traveling Positioning Accuracy 0.03/300mm X,Y,Z repositioning Positioning Accuracy 0.02mm Table Surface T-slot Extrusions Frame Welding steed X, Z Structure Ball Screw Y Structure Hiwin Rail Linear Bearings and Ball Screw Max. power Consumption 0.8Kw Max. Rapid Travel Rate 8000mm/min Max. Working Speed 6000mm/min Spindle Power Motor 3.5 Kw self cooling spindle Spindle Speed 0-24000RPM Drive Motors Stepper system Working Voltage AC220V/50/60Hz Command Language G code Operating System DSP System (Option:Mach3 PC Software) Interface USB Flash Memory 128M(U Disk) Collet ER16 X,Y Resolution <0.01mm Software Compatibility Type3 software, Ucancam software, (Option: Artcam software) Running Environment Temperature: 0~45 Relative humidity: 30%~75% Packing Size 1710 x 1250 x 1585mm Net Weight 350KG Gross Weight 370KG All the machines we have listed come with 1 year parts and service. We handle any parts or service required due to failure from manufacturing defects within a full year free of charge. The base warranty does not cover wear and tear because these machines are designed to be used in industrial production environments. However, you can purchase a 5 year extended warranty plan which covers wear and tear for an additional 27.9% of the regular purchase price. The extended warranty can be renewed. Freight to be paid by the buyer from the shipping port to the final destination.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Wisdom
Country/Region of Manufacture	China
Model	CYM0609
