Wj200-110hf - 15 Hp Hitachi Inverter Drive

US $710.00

Totowa, New Jersey, United States
Aug 27th

Open on mobile:
QR code

Model PWV2-151 Part No PWV2-151 Series WJ200 Horsepower 15.000 Rating kW 11.00 Capacity kVA 19.90 Input Voltage 380 - 480 +/- 10% Input Phase Three Input Current 29.4 Output Voltage 400 - 480 +/- 10% (3P) Output Current 24.0000 Package Height 19 Package Width 15 Package Depth 13 Package Weight 26.0 Product Height 11.7000 Product Width 7.1000 Product Depth 6.9000 Description 15 HP , 24 Amp, 11 kW, WJ200-110HF, Constant Torque Sensorless Vector AC Drive, Input: 400 - 480VAC, Three Phase Category Drives SubCategory AC Drives SubSubCategory Sensorless Vector VFD Enclosure NEMA 1 (IP20) Control Method Line-to-line sine wave Pulse Width Modulation (PWM) Control Input Frequency Range 50 - 60 Output Frequency Range 0.1 - 400 Hz VF Characteristics V/F variable V/F control (constant torque reduced torque) Sensorless vector control Overload Current Rating 150% 60 seconds Accel Decel Time 0.1 - 6000 sec. (linear/curve accel./decel.) Two stage accel./decel. setting available Starting Torque 200% or more DC Braking Operating frequency time and braking force variable. Freq Setting Operator Panel Up(1) and Down(2) keys/value setting keys. Freq Setting Potentiometer Analog Setting Freq Setting External Signal "0 ~ 10 VDC (input impedence 10k ohms), 4 ~ 20 mA (input impedence 250k ohms), Potentiometer: 1k to 2k ohms variable resistor, The frequency command is the maximum frequency at 9.8V for input voltage 0 - 10 VDC or at 19.6 mA for input current 4 ~ 20 mA. If this characteristic is not convenient contact Drives Warehouse." FWD REV START STOP Operator Run/Stop (Forward/Reverse run change by command) FWD REV START STOP External Signal Forward RUN/STOP Reverse RUN/STOP Intelligent Input Terminals "FW (Forward run command), RV (reverse run command, CF1~CF4 (multi-stage speed setting), JG (jogging command), 2CH (2-stage acceleration/deceleration command), FRS (free run stop command), EXT (external trip), USP (USP function), SFT (soft lock)" Manufacturer Hitachi

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	WJ200-110HF
Analog Output(s)	1 Output (0 - 10 VDC)
Analog Input(s)	1 Input (0 - 10 VDC / 4 - 20 mA)
Horsepower	15.0 HP
Motor Current	24.0 Amps
Manufacturer	Hitachi
Output Phase	Three Phase Output
Phase Converter	No
Warranty	2 Year Manufacturer
Output Voltage	480 VAC Output
Integrated Keypad	Yes
Input Voltage(s)	400 - 480 VAC Input
Enclosure	IP20
Digital Output(s)	1 Output (Relay)
Series	WJ200 Series
Rated Load	15 HP
Input Phase(s)	Three Phase Input
