Woodpecker I Led Style Dental Curing Light Lamp 2300mw/cm/photo-activated Pen

US $64.43

Shenzhen, China
Jul 14th

Open on mobile:
QR code

Curing Light Introduction: 1.Technical specifications 1.1Dimensions: 25mm25mm240mm 1.2 Net weight: 280g 1.3 Power source 1.3.1 Power supply: rechargeable Lithium battery 1.3.2 Battery mode: ICR 18490 1.3.3 Battery voltage and capacity: 3.7V/ 1400mAh,Battery has protection against Over-voltage, over-current and short circuit. 1.3.4 Adapter Power Input: 100V to 240V, 50Hz/60 Hz Input Power: 10VA Power Output: DC5V/1A 1.4 Light source: 1.4.1 5W high power blue light LED 1.4.2 Checking method: the LED light is fine when the light is on during operating correctly. 1.4.3 The wave length of this product can match with the clinical dental resin solidification, such as 3M, Dentsply etc. 1.4.4 Wave length: 440nm-480nm 1.5 Light intensity: P1 mode 2200-3200mW/cm2 P2 mode 1600mW/cm2~2200mW/cm2 P3 mode 1200mW/cm2~1600mW/cm2 2. Operation 2.1 Press the mode button. Following two modes are available. 2.1.1 TURBO Mode: screen shows P1, Press the time button to select of time which could be 1 and 3 seconds.Its output light intensity is about 3200mW/cm2 2.1.2 NORMAL Mode: screen shows P2, Press the time button to select of time which could be 5,10 ,15and 20 seconds.Its output light intensity is about 2200 mW/cm2 2.2 During the operation, put the disposable sleeve on the top of the main unit, aim the top at the correct position, press the ON/OFF button and the main unit will produce "Bi" sound, the curing light radiates blue light and starts working according to the set modes. Meanwhile, it starts counting down and will produce tone at every 5 seconds, it stops working when counting down to "0". 2.3 During operation, the blue light can be stopped by press the power button at any time. 2.4 After a working cycle, operator can press the ON/OFF switch to start another working cycle. Stop operating if the equipment began to heat obviously, do not restart until the equipment cool down. Suggest continues working cycle less than 10 times. 2.5 Low power dtective circuit is fixed inside of the main unit, when low power is detected, the display screen of main unit will wink, please charge in time. 2.6 When the battery needs to be charged, connect the plug of the adapter into the AC100V~240V power supply. Then connect the output plug of the adapter to the DC 5.0V input plug of the pedestal, and then the logo turn to blue. Put the main unit to the charging point of the pedestal, the display screen turn to scrolling display, and the curing lights starts charging. 2.7 After operating, take off the disposable sleeve and throw away, forbidden to reuse. 2.8 This equipment will turn off automatically if don't any action within 2 minutes, turn it on by press any button. 2.9 The depth of solidification of composite is no less than 2mm per 1 second. Material:The handle is made of plasticThe lamp holder is made of metal Photo-Activated PenPhoto-Activated Disinfection Medical Laser Equipment/F3WWPAD Light dental oral laser treatment 1 .INTRODUCTION 1.1 DESCRIPTION Photo-Activated Disinfection technology is based on two components to selectively tag and destroy cariogenic bacteria and periodontal pathogens: a solution of dilute, pharmaceutical grade tolonium chloride (a vital stain) and light of a specific wavelength (650 nm) to activate the solution. Photo-Activated Disinfection(PAD) Light-F3WW provide the light of a specific wavelength (650 nm) to activate the solution. Introduced into dental hard or soft tissue, the solution of dilute, pharmaceutical grade tolonium chloride (a vital stain) selectively targets and tags all bacteria. When the solution is activated by the Photo-Activated Disinfection(PAD) Light-F3WW,it releases singlet oxygen which ruptures the cell walls of bacteria, killing them in seconds. 1.2 Indications for Use Photo-Activated Disinfection(PAD) Light-F3WW is equally effective to activate the solution on the bacteria found in root canals, periodontal pockets, periimplantitis,carious teeth,Infection control and pain relief. Kills all bacteria including: < style="text-align:left;vertical-align:baseline;">• Streptococcus mutans • Total streptococcus • Streptococcus sobrinus • Streptococcus intermedius • Actinomyces • Lactobacillus • veilonella • Prevotella intermedia • Peptostreptococcus micros • Fusobacterium nucleatum • Porphyromonas gingivalis • Staphaloccoccus aureus • E.faecalis 2.INSTALLATION 2.1 Product content The shipping box should contain the following device components: Description QTY PAD Light main body 1 Magnetic rechargeable battery 1 Goggle 2 Light rob 2 Charge station 1 Power 1 Disposal Tip 20 User Guide 1 2.2 CLEANING AND STERILIZATION BEFORE USE ON PATIENTS The PAD Light and accessories are provided non-sterile. Cleaning and sterilization of accessories and components that come in contact with open tissue is required prior to use on patients. 2.3 Safety Do not stare into the visible light. Laser light is emitted from this device. Avoid extreme exposure. Do not point the device at anyone’s eyes. 2.4 BATTERY CHARGING The device will need to be fully charged prior to the first use. the AC recharging power cord into the unit and then into the wall socket. Charge for at least 12 hours before the first use. Recharge the device at least once every 3 weeks whether you have used the device or not. Put battery into the cylinder of the the charge station ( Contact PCB faces down), the green light turns on when it’s charging, the light will turn off when the battery get full charge. It’s about 2 hour to get full charge. 3. OPERATING INSTRUCTIONS 1.Push the Power/Select Button to power on the light. 2.Push the Power/Select Button to select the seconds for the procedure. 3.Push the Light Button to activate the Light. 4.Push the Light Button to stop the light. When the light is activated,there is a “bee” tone in every 30seconds. Note:The light will be turned off after 3 mins without any operation. Pull out the battery to stop the power. 4.WARNINGS •Because the device contains a laser, do not shine it directly into your eyes or look directly at the laser light. Do not point the PAD Light device at your or another person’s eyes. • The safety of laser devices on pregnant women has not been established. • Avoid use of the PAD Light device over, or in the area of, cancerous lesions. • The device should not be used during the following activities: • bathing or showering • sleeping • driving or operating machinery 5.MAINTENANCE Like any electronic product, the PAD Light requires proper care and handling. The following is recommended: • Do not drop the device or handle it roughly. • Do not immerse the device in water or any liquid. • If using the device on more than one person, sterilization of light rob for each use. 6.Technical Specification Wavelength 650nm ± 5nm Power 200mw Diameter 18.5mm Weight: 1100g Length without a light rod 102mm Magnetic Rechargeable Battery: Lithium Ion Diameter of the out put of the light rod 6mm Power supply 3DV rechargeable batteries Button control Sound signalisation Magnet coupled rechargeable batteries Continuous model of the laser beam FDA Statement The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If so, you can bid on this item only if you are an authorized purchaser. If the item is subject to FDA regulation, I will verify your status as an authorized purchaser of this item before shipping of the item. Seller name:Usadental City,State:SHENZHEN,China Telephone number:0755-67530389 Statement:The sale of this item may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. So you can bid it on this item only if you are an authorized purchaser. If the item is subject to FDA regulation,We have to verify your status as an authorized purchaser of this item before shipping of the item. Thanks for your understanding! Payment We only accept paypal payment,it is easy and safe. and for any other payment forms,please kindly contact us in advance. Shipping The goods you odered will be posted out in the second working day after the paymet has been made. (We will inform you via email if any delay occured due to holiday events. General shipping time is between 7-12 working days. (After the shipping started, the order will be monitored and the track of the item will be posted on paypal) About Us If you have any query or dissatisfaction, please find our customer service via eBay Message Center only. If you send message via eBay message, we'll reply you within 24 working hours. Thank you so much for your purchase. Wish you have a nice day! : -) Re: K192233 Trade/Device Name: LED Curing Light Regulation Number: 21 CFR 872.6070 Regulation Name: Ultraviolet Activator for Polymerization Regulatory Class: Class II Product Code: EBZ Dated: December 7, 2019 Received: December 16, 2019

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	Cv -gun
Dimensions	25mm240mm
Modified Item	No
Input Power	10VA
Custom Bundle	No
MPN	Does Not Apply
Relative humidity	30%~75%
Battery mode	JW-Y-1.4
Wave length	440nm-480nm
Power Output	DC5V/1A
Light intensity	1200mW/c~1600mW/c
Quantity	1 PC
Power supply	rechargeable Lithium battery
Color	White
Battery voltage and capacity	3.7V/1400mAh400mAh
Light Type	LED
Power Input	100V to 240V, 50Hz/60Hz
Brand	Unbranded
Featured Refinements	Dental LED Curing Light
Intended Use/Discipline	Dental Laboratory, Dentistry
