WR90 - N (f) Waveguide Adapter, US $940 – Picture 0
WR90 - N (f) Waveguide Adapter, US $940 – Picture 0

Wr90 - N (f) Waveguide Adapter

US $940

  • Fort Collins, Colorado, United States
  • Nov 19th
Open on mobile:
QR code
OK, so why should you purchase this adapter rather than the many bargains available from very reputable sellers here on eBay? It's straight forward, ArtCraft ELECTRONICS adapters are tested and verified by an actual RF test engineer. That's all there is to it. If you are a hobbyist who is on a restricted budget please patronize those other sellers on eBay because I know a lot of the gear they sell is very good. However, if you have a customer critical application or you just don't want to risk it you are on the right listing. Here's the test report: ArtCraft ELECTRONICS Test Report 11/19/16 1039 Manufacturer - Microwave Development Labratories - MDL Mfg. Part Nr. - 90AC46-1E Waveguide Adapter  WR90 - N(f) CONDITION – NEW (UNUSED) OLD STOCK WITH PROTECTIVE CAPS ADAPTER DEPTH 1.27 INCHES NOMINAL  ADAPTER OVERALL HEIGHT 1.6875 INCHES NOMINAL  ADAPTER OVERALL WIDTH 1.625 INCHES NOMINAL  CROSS-SECTIONAL SHAPE STYLE WR90 INTERNAL, RECTANGULAR EXTERNAL, RECTANGULAR WAVEGUIDE OUTSIDE WIDTH 1.625 INCHES NOMINAL  WAVEGUIDE INSIDE WIDTH 0.900 INCHES NOMINAL  WAVEGUIDE INSIDE HEIGHT 0.400 INCHES NOMINAL  WAVEGUIDE OUTSIDE HEIGHT 1.625 INCHES NOMINAL  TUBING WALL CONSTRUCTION - SEAMLESS SINGLE TUBING SEGMENT  MATERIAL ALUMINUM ALLOY ALL TUBING SEGMENT AND FLANGE  SURFACE TREATMENT PAINT - TUBING SEGMENT AND FLANGE OUTSIDE SURFACES  MATING SURFACES - UNPAINTED ALIMINUM ALLOY SEMI MATTE FINISH FLANGE INSIDE WIDTH 0.900 INCHES NOMINAL SINGLE FLANGE  FLANGE INSIDE HEIGHT 0.400 INCHES NOMINAL SINGLE FLANGE  FLANGE OUTSIDE WIDTH 1.625 INCHES NOMINAL SINGLE FLANGE  FLANGE OUTSIDE HEIGHT 1.625 INCHES NOMINAL SINGLE FLANGE  FLANGE INSIDE DIAMETER 1.422 INCHES NOMINAL SINGLE FLANGE  FLANGE DEPTH 0.438 INCHES NOMINAL SINGLE FLANGE  FLANGE CONNECTING FACILITY AND QUANTITY 4 UNTHREADED HOLE FLANGE CONNECTING HOLE DIAMETER 0.169 INCHES MINIMUM AND 0.175 INCHES MAXIMUM SINGLE FLANGE ALL CONNECTION FACILITIES  COAXIAL CONNECTOR SERIES DESIGNATION N CONNECTOR END DESIGN FEMALE  VOLTAGE STANDING WAVE RATIO 1.13:1 (WITHIN SPECIFICATIONS) TEST ENGINEER # PG-11-25720 Delivery is FREE in the U.S.A. Purchasers not in the U.S.A. get FREE shipping to the eBay international shipping depot. eBay will provide the cost to get your purchase to you from there.
