X-nucleo-ids01a5 Sub-1 Ghz Rf Arduino Expansion Board Spsgrf915 Stm32 Nucleo Kit

US $26.99

shenzhen, guangdong, China
Jun 9th

Open on mobile:
QR code

This auction is for X-NUCLEO-IDS01A5 X-NUCLEO-IDS01A5, Sub-1 GHz RF expansion board based on the SPSGRF-915 module for STM32 Nucleo Description The X-NUCLEO-IDS01A5 is an evaluation board based on SPIRIT1 RF module SPSGRF-915 to allow expansion of STM32 Nucleo boards. The SPSGRF-915 module operates in the 915 MHz ISM band and is FCC certified (FCC ID: S9NSPSGRF) and IC certified (IC:8976C-SPSGRF). Identification of the operating frequency of the X-NUCLEO-IDS01Ax (x= 4 or 5) is performed through two resistors (R14 and R15). It is compatible with the ST Morpho and Arduino UNO R3 connector layout. The X-NUCLEO-IDS01A5 interfaces with the STM32 microcontroller via SPI connections and GPIO pins. The user can change some of the GPIOs by mounting or removing the resistors. Key Features STM32 Nucleo expansion board based on the SPSGRF-915 X-NUCLEO-IDS01A5 contains FCC and IC certified module SPSGRF-915 (FCC ID: S9NSPSGRF and IC: 8976C-SPSGRF) SPGRF-915: 915 MHz FCC and IC certified module based on low-power, low-rate sub-1 GHz SPIRIT1 transceiver Integrated Balun (BALF-SPI-01D3) Chip antenna Compatible with STM32 Nucleo boards Equipped with Arduino UNO R3 connectors Scalable solution; can cascade multiple boards for larger systems Example firmware for point-to-point communication, compatible with STM32Cube firmware RoHS compliant Photos X-NUCLEO-IDS01A5 Packaging X-NUCLEO-IDS01A5 X-NUCLEO-IDS01A5 X-NUCLEO-IDS01A5 Back View What's Onboard Development Resources User manual Schematic Demo code Development software Wiki : www.waveshare.com/wiki/X-NUCLEO-IDS01A5 Package Contains X-NUCLEO-IDS01A5 x 1 Terms & Conditions Payment: · PayPal is the only method of payment that we accept. Shipping: · We ship items to Worldwide! · Please confirm your address in paypal, phone number is also very important. · All items will be shipped within 48 working hours on receipt of cleared payment. · We'll add a tracking number after sending the item so that you can track your parcel. Returns Policy: · We are happy to return any unused item in its original packaging within 14 days of delivery. · Buyers are responsible for the round(two-way) shipping cost. Feedback: · We'll leave POSITIVE FEEDBACK on receipt of cleared payment. · If you're satisfied with the item and our service, please leave POSITIVE FEEDBACK, it's important to us. · Once any problems occured, please contact us first. We'll try our best to work things out. FAQ: · More details(Click) If you have any question, please feel free to contact us. It's our pleasure to serve you! We appreciate your business!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	STMicroelectronics
Country/Region of Manufacture	China
Model	X-NUCLEO-IDS01A5
On board chip	SPSGRF-915
MPN	X-NUCLEO-IDS01A5
UPC	712321341457
