X-ray System, Fully Functional, Real-time Microfocus Machine 100kv 5 Micron Spot

US $38,500.00

Gilbert, Arizona, United States
Mar 11th

Open on mobile:
QR code

With an international installed base of 85 X-ray and Electron Microscopy systems, Imaging Science & Technology, LLC has been in business for more than 12 years. Included with your purchase is a 2 to 3 day visit from an Equipment Engineer with 35 years of experience. We will support your system as long as you own it and perhaps beyond. This Real-Time X-ray system is a Fein Focus model FXS 100.24 that is fully functional with on site installation & training in your facility. It now performs better than the original design (allowing 3D and many other imaging capabilities) because the camera subsystem and image processing computer have been upgraded when the system was professionally refurbished. The system now has more than 4 times the resolution of standard Feinfocus systems. Absolutely everything you’ll need to put it to work in your light industrial facility is included with this Turn-Key X-ray system. Need High Magnification X-ray? With a minimum Sample-to-Focus distance of 0.5mm, This high quality system is capable of a total Magnification > 2000 X with other features found only in new systems priced at more than $200K. Sealed - Tube X-ray sources have typically more than 12mm minimum Sample to Focus distance therefore these systems are limited to geometric magnification of about 100X (if you're lucky). That and the fact that open tubes can be rebuilt in your facility at a low cost is why Open, Transmission X-ray sources such as this, are far superior to the DISPOSABLE SEALED TUBES that cost $12K to as much as $55K to replace when they fail. The complete working system includes: The FXS 100.24 Real-Time X-ray unit. A New 22 inch, Flat Screen video monitor. A Professional Grade Image Processing Computer System. A New Scientific Grade Digital Camera. On Site installation, set up and training in your facility(Small travel charge may apply if far outside Southwestern US). 1 Year refurbishment Labor Only Warranty.(Small travel charge may apply if far outside Southwestern US). Free telephone technical support. Some Consumable Spare Parts. A set of operation and service documentation. Noted Features: Open type, Microfocus X-ray Source rated at 20 watts (typical power < 100 milliwatts). Five Axis sample stage. X, Y, Z capable of moving 50 LBS (tilt & rotate approx 8 LBS). Max. Image area Approx. 9 inch Dia. Digital Images are 1.3 Mega Pixel. Digital Images can be set to 8 Bit, 12 Bit or 16 Bit Depth. Allows Real-Time Viewing & Image Storage to HDD or USB Flash Drives. Live Video Frame Averaging, Digital Sharpening, Subtraction and more Image Processing Filters. Allows Accurate Measurement of small, encapsulated objects with 10 micron precision in Real Time. Optional Analysis software Available. Optional micro-tomography hardware & software Available. Advanced Camera System with wide dynamic range. User Text Annotation on Images. X-ray Image Computer can be tied to your network. Magnification up to 2500X. System Specifications: Less than 5 micron minimum Focal Spot size. Max. X-ray energy is 100KVP. Zero to 200 uA X-ray Tube Current. (typical iso power used is less than 60 mw). 2.33GHz Intel DuoCore, 3GB ram, 160G HD, CD / DVD, Windows 7 OS, Wireless Keyboard with Touchpad, Front panel USBs Measures 62.25 inches Wide by 47 inches deep by 78 inches tall. Weighs approx. 2750 Lbs. (shipping weight is about 3000 LB). Max. Sample Area approx. 10 by 12 inches. Mains power is 208 VAC (three phase) 60 Hz, 8 Amp (can be configured for single phase mains ). Requires compressed air at 60 to 90 psi. Radiation leakage is less than 0.2 mR/hr. Test chamber door opening: 21.25 inches wide by 17.25 inches tall . Rebuilding Includes: Complete clean and rebuilding of the Open Microfocus x-ray tube. Tube Target replaced. Complete Cleaning and Testing of High Voltage power supply and associated components. X-ray Cabinet Shielding Integrity Tested Including Full Radiation Leakage Survey. X-ray camera Upgraded to a High Resolution Scientific grade Digital camera. Integration of modern Image Acquisition and Processing Computer with Flat Screen Monitor. Software features allow X-ray tube to be operated at less than 100 milliwatts to greatly increase lifetime of consumable tube components. . Cleaning, Calibration and Lubrication of all Mechanisms. Cosmetic damage was repaired. Image Intensifier replaced. Vacuum Ion Gauge cleaned. Careful, Thorough testing of the whole system for more than 60 days. If you have a question and would like to speak with an engineer about this system you may call: (480) 748-9239. You are welcome to visit our facility to operate this system yourself using some of your samples. This easy to operate, Real Time Microfocus X-ray system is in great electrical and physical condition. The system will serve well in your small electronics manufacturing, testing or service facility. This system was refurbished in the USA. The system will need to be shipped via common freight carrier. We’ll help you obtain a shipping quote from the 85210 zip code to your location. We have good local contacts that can save you money on crating. We'll be available for service in the future should you ever need it or, you can obtain a service contract from the OEM. If you are interested in the latter, we will put you in touch with the OEM's service organization. Please consider: This isn't a beaten-up Junker with specs copied from a manufacturer's web page. It has been professionally rebuilt and tested by an equipment engineer who is registered with the Arizona Radiation Regulatory Agency. Disclaimer: By bidding on this x-ray device the buyer claims they are of 18 years or older and agrees that x-ray radiation is potentially harmful and that high voltage is dangerous. The buyer accepts all responsibility for any property damage or any accident, injury, illness, or death to his or her person or to other persons resulting from his or her use, abuse or misuse of this device. The seller does not guarantee the personal security of the buyer or any other persons using the item in a security application and is therefore not responsible for any acts of violence occurring through the use of weapons screened by the item. The item is not intended for medical, dental or veterinary use. Winning bidder: Payment is to be made by a major bank cashier’s check or your company check only. International wire transfers are possible. The sale is final. Actual shipping, crating and packing costs are to be paid for by the winning bidder. Shipping is to be arranged by the winning bidder but we will help you obtain low cost quality shipping. The seller reserves the right to cancel the winning bid if the x-ray machine has not been removed from seller’s facility within 30 days of the auction’s closure. We cannot store your machine for you longer than 30 days. The item will ship only when payment has been made in full. Seller reserves the right to refuse or cancel bids from bidders with negative feedback. International buyer will work through a Customs Brokerage Agency for export shipping paid for by the buyer. We have contacts that are happy to help you ship worldwide.

“In very good condition and fully functional. This great Real Time X-ray system will be properly installed in your facility and your employees trained to operate and maintain it the same week that you buy it. It can be shipped in a fully enclosed new, shock resistant crate (at your cost) when you give the word.”

Brand	Read the Description
Country/Region of Manufacture	Germany
Model	Read the Description
Country of Manufacture	Germany
