Xenetech Laser Engraver 60 Watt! Xle 2436 Top Of The Line Model

US $14,900.00

Arlington Heights, Illinois, United States
Jan 30th

Open on mobile:
QR code

ANY QUESTIONS CALL 847 910 0921 100 percent operational and ready to go to work!!!! XLT & XLE 2436 Laser Engraving System - Specifications Table surface area: 24" x 36 " (609.6 x 914.4 mm) • Engraving area: 864 sq. in. • Machine Weight: 340 lbs. (154 kg) • Shipping Weight:600 lbs. (272 kg) • Maximum Z travel: 10" (254 mm) • Ships with laser accessory kit and Xenetech Graphic Workstation Professional Engraving Software: XGW-32, and third party (CorelDraw!™) Print Driver • Dimensions:Width 54.5" (1384.3 mm), Height: 38"(965.2 mm), 41.5"(1054.1 mm), Depth 33.5" (850.9 mm) Revolutionary touch screen control panel featuring: Pause/cancel Table up/down On-the fly Speed and Power control Power control Auto-focus; choose focus location on odd shaped pieces Job preview with pan and zoom Save up to four different home positions for X, Y, and Z, for use with cylindrical fixture, vector table, etc. Real time job timer Job queue that loads jobs and job information from any computer on the network End of job signal on/off Red diode pointer on/off Direct import HPGL control Air assist on/off Exhaust blower delay exhausts gasses at the end of a job Imperial and metric settings Mottle settings to control laser pulsing during raster Diagnostics for feedback on functionality of system components State-of-the-Art motion system featuring: Lifetime bearing warranty Adjustable belt tension for the ultimate fine tuning Light weight components that allow the fastest acceleration and fastest speeds in the industry Double break design limit switches that are protected from moisture and dust by a silicon rubber boot Superior bearings: No lubrication required Push debris off of the rail as the machine runs Significant speed capabilities over recirculating ball bearings Unrestricted acceleration Larger contact surface than point contact recirculating bearings Low friction coefficient Abrasion resistant Reduced mechanical vibration Chemically resistant to alcohol, fuel, strong alkali, and most weak acids Operating temperatures from –58° F to 194° F Heavy duty servo x-axis motor (XLT only) for high speed with absolute accuracy including: Faster moves and settling times Superior tracking accuracy Adaptive inertia matching technology for fine tuning Peak power of 614 watts Peak torque of 164 oz. inches Easy change optic system including: Optics substrates and coatings are rated up to 1,000 Watts Color coded optic holders for different mirrors and lenses. Ability to remove optics for cleaning or replacement without losing alignment Quick align design for beam alignment Interchangeable tube design including: The highest quality tubes on the market Ability to replace tube assembly or upgrade without having to adjust beam alignment State-of-the-Art cabinet design including: Rigid monocoque design to maximize strength while minimizing weight Exhaust design placement and cabinet seal for maximum air flow across engraving area Key-locked access panels for easy removal Removable back panel for pass through capability Industrial locking casters rated at over 200 lbs each High quality lid and front door concealed hinges Gas strut supported lid All stainless steel hardware to prevent corrosion High Speed, continuous motion controller including: AMD SC 520 microprocessor 32-bit Architecture and 64-bit FPU On-board LED diagnostics Optional Accessories Dual Head Air Assist Laser Cutting Table Cylindrical Engraving Attachment Large 24" x 36" (610 x 914.4 mm) engraving area with 10" (254 mm) of clearance; Honeycomb core table for strength. User controlled Red diode pointer for proofing and positioning beam Fires while engraving or can fire at all times Motorized table height adjustment Three point table mount for stability Protection from laser beam (class IIIa laser) End of job signal Xenetech Graphic Workstation Professional Engraving Software: XGW-32 Xenetech 32-bit Print Driver Ethernet capability Rubber Stamp Mode
