Xhc Mach3 Mb04 Wireless Bluetooth Mpg Pendant Lcd Handwheel Cnc Controller

US $550

Lafayette, Colorado, United States
Jun 10th

Open on mobile:
QR code

Description: Model: HB04 Condition: Brand New From Factory Weight: 700g Wireless operation, to bring you convenience and practicality The RF is standard with 2.4G ISM, the TX power is 0DB and the RX sensitivity is -98DB. The RF has 64-channel, the channel gap is 1 MHz. 15 meter wireless transmission distance, stable and reliable data transmission. Low power consumption, automatic learning ID number It max support 4 axis. The 4th axis- A axis, no A=0 function ( A axis functions are not as much as the other 3 axis). Real-time display of large screen LCD This handwheel is widely used in stone carving, advertising, furniture making, plate making, and other industries. Features: The RF is Standard with 2.4G ISM ,the Tx power is 0DB and the RX sensitivity is -98DB The RF has 64 channels,the channel gap is 1Mhz The transmission distance is further than 15 meters with no barrier The protocol Designed with high performance; Low power consumption;Automatic learning ID Number To jump frequency Adaptively when noised ,which can work with 2.4G wireless Mic ,Wlan and Bluetooth etc. devices. 32 sets Wireless Handle work fine at the same time in one room ,with no-interference each other Handwheel functionality - 100PPR the manual pulse generator output Display, real-time display of the machine the workpiece coordinates, mechanical coordinates. Coordinates X, Y, and Z three-axis with the screen display Axis selection function, the band axis selection switch, you can choose the X, Y, and Z axis With the function of the hand wheel boot: hand wheel guide, facilitate the adjustment process. ShuttlePro Installation 1. When Mach3 is installed , there will be a folder created named ?PlugIns? in the Mach3 folder. This folder is the location to put and Plugin files that you want Mach3 to know about. Place ?ShuttlePro.dll? in the \Mach3\PlugIns folder. Check and make sure it is there. 2.Setup diver for automatically set the knife height function M930.m1s copy the installation directory to the MACH3 ..\Mach3\macros\Mach3Mill 3. Now that the ShuttlePro.dll file is in \Mach3\PlugIns, the next step is to connect the huttlePro. If you are certain that your ShuttlePro is working and your hardware is working then you can simply plug in the ShuttlePro to one of the USB ports. 4. Once the ShuttlePro is connected, start Mach3 and go to the ?Config? menu choice and select ?ConfigPlugins?. You should see the ShuttlePro choice with a green checkmark in front of it. If it is not checked, you can check it. The checkmark means that Mach3 found the ShuttlePro on tartup. Click the ?CONFIG? in yellow and set the buttons as you wish. 5. Once you have the proper button selected in the Mach3 ShuttlePro Plugin CONFIG menu, your Shuttle device should be working properly. Package included: 1x Wireless USB Receiver 1x CNC Wireless Remote Handle 1x CD for manual and mach3 software
