Xilinx - Parallel Cable Iv Dlc7

US $100.00

Missoula, Montana, United States
Jan 30th

Open on mobile:
QR code

This sale is for 2 Xilinx DLC7 1 new and 1 used Xilinx DLC7 Parallel Cable IV The Xilinx Parallel Cable IV (PC4) is a high-speed download cable that configures or programs all Xilinx FPGA, CPLD, and ISP PROM devices. The cable takes advantage of the IEEE 1284 ECP protocol and Xilinx iMPACT software to increase download speeds over eight times faster than existing solutions. The cable automatically senses and adapts to target I/O voltages and is able to accommodate a wide range of I/O standards from 1.5V to 5V. PC4 is designed for use in a desktop environment. PC4 supports the widely used industry-standard IEEE 1149.1 boundary-scan (JTAG) specification, the Xilinx slave-serial mode for Xilinx FPGA devices, and serial peripheral interface for serial-access flash PROM programming. PC4 supports indirect programming of select flash memories including the Platform Flash XL configuration and storage device (via an FPGA JTAG port). The cable interfaces to target systems using a ribbon cable that features integral alternating ground leads to reduce crosstalk and improve signal integrity. The cable is externally powered from either a power brick or by interfacing to a standard PC mouse or keyboard connection. A bi-color status LED indicates the presence of operating and target reference voltages. Features: Download speed of up to 5 Megabits per second (Mb/s) Over eight times faster than Xilinx® Parallel Cable III using Xilinx ISE® iMPACT download software Embedded Development Kit (EDK) compatible ChipScope™ Pro Analyzer compatible In-system configures the following Xilinx devices: Virtex® series FPGAs Spartan® series FPGAs XC9500/XC9500XL/XC9500XV CPLDs CoolRunner™ (XPLA3)/CoolRunner-II CPLDs XC18V00 ISP PROMs XC4000 series FPGAs Platform Flash XCF00S/XCF00P/XL PROMs LED status indicator Automatically senses and adapts to correct I/O voltage Interfaces to devices operating at 5V (TTL), 3.3V (LVTTL), 2.5V, 1.8V, and 1.5V In-system programs serial-access flash PROMs via the serial peripheral interface (SPI) Supports IEEE 1149.1 (JTAG), Xilinx slave-serial mode, and serial peripheral interface (SPI) J-Drive IEEE 1532 Programming Engine compatible Compliant with IEEE 1284 Level 2 Electrical Specification Externally powered using keyboard/mouse splitter cable or AC power brick Compatible with ECP-compliant I/O controllers for highspeed, bidirectional communication Intended for development — not recommended for production programming

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	XILINX
Country of Manufacture	United States
Model	DLC7
