Xilinx Spartan-3e Xc3s1200e Fpga Module. Development Board Xmf3e

US $37

Tallinn, Harjumaa, Estonia
Mar 5th

Open on mobile:
QR code

Introduction XILINX SPARTAN-3E XMF3E FPGA module is a low cost and easy to use tool. Designed for rapid prototyping and implementing FPGA designs. This module can be used independently, for education, or can be used as core module, for bigger design. Features 1) XILINX XC3S1200E FGG400 4C FPGA * 1200000 gates (19512 Logic Cells) * 28x 18x18 hardware multipliers * 28x 18K-bits block RAMs (504K) * 8 Digital Clock Managers* Fully supported by latest XILINX design tools 2) XILINX XCF08P FLASH * 8 Mbit Platform Flash PROM * IEEE Standard 1149.1/1532 Boundary-Scan (JTAG) support for programming * Endurance of 20000 Program/Erase Cycles* Fully supported by latest XILINX design tools 3) Reset supervision IC and reset push button 4) Onboard IO peripherals * 4 LEDs * 1 push button* 50 MHz CMOS crystal oscillator 5) Handy configuration * Onboard JTAG header * Mode select jumper* DONE LED 6) Onboard power supply * Input voltage range 3.5V – 6.5V * TPS75003, Triple-Supply Power Management IC for 3.3V, 2.5V and 1.2V * 1.8V LDO* POWER-ON LED 7) 76 independent I/O routed to the connectors * Four 1x19 male connectors (18 IO, 1 VCC or 1 GND) * 2.54mm pitch for all connectors * 3.3V IO voltage* Small 50x50mm PCB designed to fit on the prototyping board with 2.54mm pitch Schematics, user's guide, demo projects Package includes: 1x XMF3E FPGA module Standard traceable shipping worldwide. Within European Union, most of the packages are delivered in 3-6 work days. Check my other auctions

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	PLDkit
Country/Region of Manufacture	Estonia
Model	XMF3E
