Xinje 2 Phase Stepper Drive Dp504-l Up To 40vdc 5.0a 200hz 200 Subdivision New

US $121.00

shenzhen,Guangdong, China
Jan 29th

Open on mobile:
QR code

Xinje 2 Phase Stepper Drive DP504-L Up to 40VDC 5.0A 200Hz 200 Subdivision New Features: Low motor running noise, complete digital control Power supply up to 40VDC Output current up to 5.0A Dynamic selectable subdivision up to 200 Can drive any 4, 6, 8 lines two phases stepper motor below 5.0A Optical isolation input, over current and over voltage protection Specifications: Item Minimum Type Maximum Input Voltage(VDC) 20 36 40 Output Current(A) 0 - 5 Logic input current(mA) 4 7 16 Step Pulse Frequency(KHz) 0 - 200 Insulated Resistance(M?) 500 - - Ambient Temperature 0 °C ~50 °C Peak Temperature 70 °C Humidity 40~90% RH(No condensing, dry bulb) Resistance 5.9m/s2 Max Storage Temperature -20 °C ~65 °C External Dimensions 138x85x38mm Current setting Can set any current levels between 0~5.0A with single-turn potentiometer. Product type DP504: pulse signal connects to 24V; DP504-L: pulse signal connects to 5V. Subdivision setting subdivision times steps/round(1.8°/step) SW2 SW3 SW4 SW5 1 200 OFF OFF OFF OFF 2 400 OFF OFF OFF ON 4 800 OFF OFF ON OFF 8 1600 OFF OFF ON ON 16 3200 OFF ON OFF OFF 32 6400 OFF ON OFF ON 64 12800 OFF ON ON OFF 128 25600 OFF ON ON ON 5 1000 ON OFF OFF OFF 10 2000 ON OFF OFF ON 20 4000 ON OFF ON OFF 25 5000 ON OFF ON ON 40 8000 ON ON OFF OFF 50 10000 ON ON OFF ON 100 20000 ON ON ON OFF 200 40000 ON ON ON ON We accept Paypal only. Contact information: Fast To Buy Ltd 1207, International E-Commerce Industrial Park of FuTian, Shangmeilin, Futian district, Shenzhen, 518049, CN Phone: +0086 13724354369 or +0086 755 82546545 email: ebay@fasttobuy.com TradeManager: fasttobuy skype: ebayfasttobuy our working time: EST 9:00AM ~ 6:00 PM We only use the DHL, FEDEX, UPS and EMS to ship the orders. Fast To Buy Ltd decide to choose the suitable express service for the orders . Fast To Buy Ltd is not responsible on the custom tax for any order. Customer should pay for the custom fee in any case. Warranty: Fast To Buy Ltd make sure the item is brand new with original package and offer 1 year warranty for the quality. Return policy: If you want to return the item, please contact us in 14 days first and make sure the package is un-opened. The buyer has to pay for the go and back delivery cost and the custom fee of each country. Fast To Buy Ltd will make refund for the part in 24 hours after receiving it. This returns policy does not affect your statutory rights. Fast To Buy Ltd won't take any responsibilities if customers provide wrong shipping infomation such as address, code or phone number etc. Kindly note: Pls check and confirm the part NO. and your application before place order, we can accept return or refund within 14 days for the quality reason only, thank you.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Xinje
MPN	DP504-L
Model	DP504-L
Country of Manufacture	China
