XL6009 DC-DC Adjustable Boost Power Converter Supply Module Replace LM2577 Kit, US $2.70 – Picture 0

XL6009 DC-DC Adjustable Boost Power Converter Supply Module Replace LM2577 Kit, US $2.70 – Picture 1

XL6009 DC-DC Adjustable Boost Power Converter Supply Module Replace LM2577 Kit, US $2.70 – Picture 2

XL6009 DC-DC Adjustable Boost Power Converter Supply Module Replace LM2577 Kit, US $2.70 – Picture 3

Xl6009 Dc-dc Adjustable Boost Power Converter Supply Module Replace Lm2577 Kit

US $2.70

Singapore, Singapore
Jan 29th

Open on mobile:
QR code

Shipping Payment Return Policy&Feedback Contact Us Product Show Desription Description IN-IN + input Positive Input Negative! Positive output OUT + OUT-output negative Test comparison sample reference: Input 3V Output 12V 0.4A 4.8W Input 5V Output 12V 0.8A 9.6W Input 7.4V Output 12V 1.5A 18W Input 12V Output 15V 2A 30W Input 12V Output 16V 2A 32W Input 12V Output 18V 1.6A 28.8W Input 12V Output 19V 1.5A 28.5W Input 12V Output 24V 1 A 24W Vin * Iin * Efficiency = Vout * Iout Vin: Input Voltage Iin: input current Vout: Output Voltage Iout: output current DSN6009 4A is a high-performance step-up switching current (BOOST) module. The module uses the second generation of high-frequency switching technology XL6009E1 core chip performance than the first generation technology LM2577. XL6009 boost module at a lower cost, superior performance, LM2577 module is about to be eliminated. ? Wide input voltage 3V ~ 32V, optimum operating voltage range is 5 ~ 32V; ? Wide Output voltage 5V ~ 35V; ? Built-4A efficient MOSFET switches enable efficiency up to 94%; (LM2577 current is 3A) ? high switching frequency 400KHz, can use a small-capacity filter capacitors that can achieve very good results, the ripple smaller and smaller. (LM2577 frequency only 50KHz) Technical parameters: DSN6009 boost module Module Properties Non-isolated boost (BOOST) Rectification Non-Synchronous Rectification Input Range 3V ~ 32V Output Range 5V ~ 35V Input Current 4A (max), no-load 18mA (5V input, 8V output, no-load is less than 18mA. Higher the voltage, the greater the load current.) Conversion efficiency <94% (greater the pressure, the lower the efficiency) Switching frequency 400KHz Output Ripple 50mV (the higher the voltage, the greater the current, the greater the ripple) Load Regulation ± 0.5% Voltage Regulation ± 0.5% Operating Temperature -40 °C ~ +85 °C Dimensions 43mm * 21mm * 14mm (L * W * H) Package: 1 x L6009 DC-DC Adjustable Step-up boost Power Converter Module Shipping Item will be shipped within 24 -48 hours after full payment is received. The Item will be shipped by air mail,Normally the shippment to worldwide is used to take 20 to 25 business days, exclude Sat & Sun. Payment We only accept payment through Paypal. Payment must be received in 7 business days of auction closing. Please leave note for your special request in ebay note when you pay the order. Any special request cannot be accepted after 24 hours of payment, because most of orders will be processed instantly and same day dispatched. Return Policy&Feedback If the item is defect when you receive it or you are not satisfied with it, please return it within 14 days for a replacement or money back. But the items must be back in factory condition. Please contact us and double check the return address before you return it. If is item is defective in 3 months, you can return it to us. We will send you a new replacement after receiving the defective item Contact Us We care about our valued buyers, if you have any questions, our Customer Service staffs will be very glad to help you. We try our best to reply your email as soon as possible, please kindly allow 24 hours(working day) for us to response. Thank you. We greatly appreciate your POSITIVE feedback. Please do NOT leave negative or neutral feedback without any contact
