Xl6009 Dc-dc Adjustable Step-up Boost Power Converter Module

US $84

CHINA, China
Feb 21st

Open on mobile:
QR code

Product Detail XL6009 DC-DC Adjustable Step-up boost Power Converter Module Technical parameters: Model Specification DSN6009 boost module Module Properties Non-isolated boost (BOOST) Rectification Non-Synchronous Rectification Input Range 3V ~ 32V Output Range 5V ~ 35V Input Current 4A (max), no-load 18mA (5V input, 8V output, no-load is less than 18mA. Higher the voltage, the greater the load current.) Conversion efficiency <94% (greater the pressure, the lower the efficiency) Switching frequency 400KHz Output Ripple 50mV (the higher the voltage, the greater the current, the greater the ripple) Load Regulation ± 0.5% Voltage Regulation ± 0.5% Operating Temperature -40 ℃ ~ +85 ℃ Dimensions 43mm * 21mm * 14mm (L * W * H) IN-IN + input Positive Input Negative Positive output OUT + OUT-output negative Test comparison sample reference: Input 3V Output 12V 0.4A 4.8W Input 5V Output 12V 0.8A 9.6W Input 7.4V Output 12V 1.5A 18W Input 12V Output 15V 2A 30W Input 12V Output 16V 2A 32W Input 12V Output 18V 1.6A 28.8W Input 12V Output 19V 1.5A 28.5W Input 12V Output 24V 1 A 24W Vin * Iin * Efficiency = Vout * Iout Vin: Input Voltage Iin: input current Vout: Output Voltage Iout: output current DSN6009 4A is a high-performance step-up switching current (BOOST) module. The module uses the second generation of high-frequency switching technology XL6009E1 core chip performance than the first generation technology LM2577. XL6009 boost module at a lower cost, superior performance, LM2577 module is about to be eliminated. Wide input voltage 3V ~ 32V, optimum operating voltage range is 5 ~ 32V; Wide Output voltage 5V ~ 35V; Built-4A efficient MOSFET switches enable efficiency up to 94%; (LM2577 current is 3A) high switching frequency 400KHz, can use a small-capacity filter capacitors that can achieve very good results, the ripple smaller and smaller. (LM2577 frequency only 50KHz) Sales Policy Your bid is a contract - Place a bid only if you're serious about buying the item. If you are the winning bidder, you will enter into a legally biding contract to purchase the item. If payment is not received within 7 days, item may be offered to the next highest bidder or relisted at the seller¡¯s sole discretion. VAT (Value-Added Tax) is buyer's responsibility. However, we will try our best to minimize it. Shipping Detail Transport Country Time (workday) China Post(HK Post) USA,Canada,Australia Westem Europe Eastem Europe,South America Japan,Singapore,Thailand,Malaysia,India Other countries 10-21days 15-21days 20-30days 14-25days 30days or more EMS,DHL UPS,TNT FEDEX USA,Canada,Australia Westem Europe Eastem Europe,South America Japan,Singapore,Thailand,Malaysia,India Other countries 5-10days 7-14days 10-20days 7-15days 20days or more Economy Shipping: Shipping cost: Free Carrier: China Air Mail Tracking No. Unavailable Standard Shipping: Carrier: China Air Mail or HongKong Air Mail Tracking No. Available Item will be shipped within 3 working days after full payment is received. You should receive item within 2-4 weeks. Email us if not receive items after 21 working after full payment sent. We only ship to the approved address given in PayPal payment. Please make sure payment address in PayPal is correct. Any non-received items caused by invalid address registered on PayPal are not in our full refund or replacement policy. Payment Method We accept PayPal only . We ship within 3 business days of receiving payment. Serious bidders only, please. Orders will be cancelled and an unpaid item dispute filed if payment is not received within 10 days of purchase. Return Policy We offer 90 days free warranty (except consumables).we stand behind every product we sell.If you're not pleased with your purchase, we'll be happy to make an exchange or refund the product price less S&H within 7 days of your purchase. For any exchange or refund, we need the original receipt or a record of the purchase in our system, and the product must be in its original condition, including the box, packaging, and all accessories. Please allow up to 10 business days for returns to be processed. Shipping and handling charges are not refundable. About Us We are professional EBAY sales team and lots of ebay buyers very satisfied with our services.You can enjoy top-quality product and high-quality services from us, Trust me that you will have a pleasant shopping experience in here. Your partner for managing your online business
