Xprotolab Plain Oscilloscope, Logic Analyzer, Waveform Generator, Sniffer, Fft

US $20.00

Palmetto, Florida, United States
Jan 29th

Open on mobile:
QR code

Manual Schematics Code Hex BOM Interface Videos Pictures FAQ Forums The Xprotolab Plain is the most inexpensive but feature rich oscilloscope in the market. It consists of a simple DIP module with a USB interface. Visualization of the signals and controlling the oscilloscope is done on the PC interface software (open source). The Xprotolab Plain is similar to the original Xprotolab, but doesn't have the display and buttons, so it only works with the USB interface. The board measures only 1 x 2 inches, and can be mounted directly on a breadboard. The Xprotolab can also be used as a development board for the AVR XMEGA microcontroller. Features: Mixed Signal Oscilloscope: Simultaneous sampling of analog and digital signals. Advanced Trigger: Normal / Single / Auto, with rising or falling edge and adjustable trigger level. Meter Mode: DC, Average, Frequency and Pulse Counter readout. XY Mode (Plot Lissajous patterns or see the phase difference between two waveforms). Spectrum Analyzer with different windowing options and selectable vertical log. Horizontal and Vertical Cursors with automatic waveform measurements. Arbitrary Waveform Generator with Frequency Sweep. Display options: Persistence, Different grid options, and more. General Specifications: ATXMEGA32A4U 32KB Flash, 4KB SRAM, 1KB EEPROM Module size: 1.980" x 1.01" PDI interface. USB connectivity: Windows, Android Logic Analyzer specifications: 8 Digital Inputs, 3.3V Level Maximum sampling rate: 2MSPS Protocol Sniffer: UART, I2C, SPI Frequency Counter: 16MHz Internal pull up or pull down. Buffer size: 256 Oscilloscope specifications: 2 Analog Inputs Maximum Sampling rate: 2MSPS Analog Bandwidth: 200kHz Resolution: 8bits Input Impedance: 1M? Buffer size per channel: 256 Input Voltage Range: -14V to +20V AWG specifications: 1 Analog Output Maximum conversion rate: 1MSPS Analog Bandwidth: 44.1kHz Resolution: 8bits Output current > +/- 7mA Buffer size: 256 Output Voltage: +/- 2V

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	Xprotolab Plain
Sample Rate	Less than 200MSa/s
MPN	GT-0007
Make	Gabotronics
Type	Digital
Number of Channels	2 Analog 8 Digital
Bandwidth	Less than 60MHz
Country/Region of Manufacture	United States
Channels	Over 4
