Xy-pwm1 Signal Generator Digital Display Pwm Pulse Frequency Duty Ratio Adj N3c1

US $12.56

Shenzhen, China
Jul 7th

Open on mobile:
QR code

Xy-Pwm1 Signal Generator Digital Display Pwm Pulse Frequency Duty Ratio Adj N3C1 Frequency is divided into four areas: automatic switching: 1.XXX (without decimal point): the smallest unit is 1Hz, and the value range is 1Hz~999Hz;The minimum unit of 2.X.XX (decimal point in 100 bits) is 0.01Khz, and the value range is 1.00Khz~9.99Khz; 3.XX.X (decimal point in ten places): the smallest unit is 0.1Khz; and the range is 10.0KHz~99.9KHz. 4.X.X.X (decimal point in ten bits and 100 bits): the smallest unit is 1Khz; and the range is 1KHz~150KHz.E.g. frequency display: 100 indicates PWM output 100Hz pulse;1.01 represents the pulse of PWM output 1.01K.54.1 represents the pulse of PWM output 54.1KHz.1.2.4 indicates the pulse of PWM output 124KHz.Duty cycle:0~100%;All settings are saved by power down. DIY Supplies:Electrical Display Size:2.9 Inches and Under 100% brand new and high quality PWM output can set frequency and duty cycle respectively. Parameter setting: Module has four independent keys, used to set the frequency and duty cycle, support short press (increase or decrease a unit) and long press (ly increase or decrease), very simple, set the parameters automatically save, power loss is lost. Scope of application: 1.is used as a square wave signal generator to generate square wave signals for experimental development. 2.is used to generate square wave signals that control motor drives. 3.generate adjustable pulse for MCU use; 4.generate adjustable pulses to control related circuits (PWM dimming and speed regulation applications). Working voltage: 3.3~30V Frequency accuracy: accuracy is about 2% in each range Signal load capability: output current can be around 5~30mA Output amplitude: PWM amplitude is equal to supply voltage Ambient temperature: -20~+70 Celsius Dimensions: 3.7x4.3x7.8cm/1.46x1.69x3.07inch Color: Black Material:plastic Package Contents: 1 * Signal Generator Module On Jul-06-21 at 22:53:09 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	MPN	Does Not Apply
Modified Item	NO
Brand	Unbrand
Modification Description	No
Marke	SODIAL
Hersteller	SODIAL
Model	Regular
Custom Bundle	Regular
Country/Region of Manufacture	China
Bundle Description	No
UPC	193571493019
ISBN	193571493019
EAN	193571493019
