Yamashita Denso Automated Solar Simulator Iv And Resistance Hi-pot Test Line

US $7200

Ventura, California, United States
Jun 22nd

Open on mobile:
QR code

PRODUCT DESCRIPTION Uni-Solar HISEC MX-III Hitach Setsubi Automated Solar Cell I-V Hi-Pot Solar Simulator Test Line. Manufactured by Hitachi Setsubi Engineering Co., LTD for Uni-Solar in 2010. The test line is used for final qualification of the condition of solar modules manufactured by a solar cell production line. Performance characterization by Solar Simulator and Hi-Pot test to inspect for electrical safety. The test line consists of the following major components. Load Conveyor (5,080mm x 2,420mm) for solar panels up to 18 feet in length with touch screen operator panel. Solar Simulator: Yamashita Denso (YDC) PXS-0855MP 6000mm x 900mm 10msec 40 KVA single flash pulse xenon lamp test system JISC8912 Class A and ASTM E927 Class A. I-V Curve Measuring System follows JIS C8913 and ASTEM. Measurement range 80V 15A. Measurement Points: 30 at 1000W/m2. Integrated Window XP based software testing analysis and touch screen operator panel. Hi Pot Tester designed to submerge and test voltage of 2 modules at a time with two Kikusui TOS9201 Voltage Testers with touch screen operator panel. Air Knife system blows off water on module surface after Hi-Pot test utilizing an 8.8kw blower. Overhead Pickup Transport Gantry: Pickup 1 conveys modules from load conveyor to solar simulator. Pickup 2 conveys modules from solar simulator to Hi-Pot testers. Pickup 3 conveys modules from Hi-Pot tester to unload conveyor. Gantry moves in vertical and horizontal direction to convey modules. Unload Conveyor (6,080mm x 3,420mm) picks up tested panels and conveys them to the take off position with touch screen operator panel. Power Distribution Panel: 208 Volts 3 Phase 300 Amp 60 Hz Required. Control Panel: 208 Volts 3 Phase 200 Amps Required. Software: Windows XP based software custom programmed for Uni-Solar panel specifications. System includes solar panel drill, cutter and pre and post load tables, spare parts, extra Xenon Lamps, complete manuals and schematics. Dimensions and Weight: 35 feet wide by 38 feet deep by 10 feet tall. Approximately 40,000 pounds. System will ship in approximately 4 40 foot containers. PRODUCT SKU SKU: 44103 Questions? Please call us Toll Free: (888)488-6550 This item offers LOCAL PICK-UP only. If you see FREE SHIPPING anywhere else, it is because there is no cost for you to retrieve the item at our warehouse. Should you prefer that we ship (where possible), please contact us for a shipping quote. We cannot ship for free. Photos are of the exact item we are selling, unless, there are multiple quantities listed, or we had multiple quantities and are down to our last item. Product photos shown are of a typical item from that lot. Please understand serial numbers shown in photos may not match the item you receive. If in doubt please contact us by messaging us or calling us prior to bidding. If you have any questions Please Contact us! We're happy to answer any questions you may have. Business Hours: 8:00 am to 5:00 pm (PST) Monday to Friday We are closed on Weekends and all major US holidays. Warehouse Delivery Hours: 8:00 am to 5:00 pm PST Monday to Friday Phone: 805-648-3300 Fax: 805-648-3350 Physical/Mailing Address: Recycled Goods, Inc. 3820 N. Ventura Avenue Ventura, California 93001 United States of America Location visits by appointment only. On Jun-15-16 at 00:29:00 PDT, seller added the following information:
