Yaskawa V1000 Variable Frequency Drive 480vac 5hp (cimr-vu4a0009fa) With Filter!

US $330

Clay Center, Kansas, United States
Nov 7th

Open on mobile:
QR code

YASKAWA V1000 VARIABLE FREQUENCY DRIVE 480 VAC // 3-PHASE // 5 HORSEPOWER MODEL: CIMR-VU4A0009FA THIS UNIT IS A 480VAC 3-PHASE 5HP MODEL WITH OPEN CHASSIS & THE OPTIONAL SI-N3/V DEVICENET MODULE. THIS UNIT HAS BEEN TESTED & IS 100% FUNCTIONAL! The V1000 is a world-class compact current vector drive that defines a new world standard. Demands for efficient production and better maintainability are on the rise, spurred by global competition. Yaskawa drives have earned a reputation for high performance, high functionality, and high quality. The V1000 provides a world of power in the palm of your hand! INCLUDES THE FOLLOWING EXTRAS: SCHAFFNER FS23639 10 AMP LINE FILTER OPTIONAL SI-N3/V DEVICENET MODULE USING A CN5 DRIVE CONNECTION. Performance Features Ratings: 5 HP at 480 VAC 3-ph Overload Capacity: 150% for 60 sec. (Heavy Duty) 120% for 60 sec. (Normal Duty) Control Methods: V/f Control, Open Loop Current Vector Control, PM Open Loop Current Vector Control Simple closed loop speed control DC injection braking, ramp to stop Electronic reversing Adjustable accel/decel:0.01 to 6000 seconds Controlled speed range: 40:1(1) 100:1(2) Speed Regulation: ± 0.5 to 1% with slip compensation(1) ± 0.2%(2) Displacement power factor: 0.98 Output frequency: 0 to 400 Hz Frequency resolution: 0.01 Hz with digital reference 0.06 / 60 Hz with analog reference Frequency accuracy: 0.01% with digital command 0.5% with analog command Volts / hertz ratio: infinitely adjustable pattern DC Injection braking: adjustable amplitude, duration, current limited Torque boost: full range, auto Power loss ride-thru: 0.5 sec. Speed search Auto restart 3 Critical frequency rejection settings Slip Compensation Energy $avings Function Enhanced PID with loss of feedback function Protective Features Current limit, stall prevention during accel, decel, and run Motor and drive overload Over voltage prevention function Instantaneous over current Short circuit Under voltage Heatsink overheat Ground fault protection Over/under torque Short circuit current rating: 30KA rms sym. Options Dynamic Braking resistor (external) Multi-lingual, full-text remote LCD Profibus-DP, DeviceNet Communications Modbus TCP/IP, EtherNet/IP Communications Design Features Dual microprocessor logic Digital keypad operator, 5 digits LED status display Remote Mount Keypad Capability RJ-45 Style Digital Operator Connector 7 multifunction digital inputs 3 multifunction digital outputs Hardwire baseblock (EN954-1 Cat. 3) Programmable form C output contact for customer use: 1A at 250 VAC or 30 VDC 24 VDC control logic compatible with sourcing or sinking outputs (PNP or NPN) Carrier frequency: 15 kHz max; swing PWM 16 multi-speed settings plus jog speed 2 Remote speed references 0-10 VDC (20 kohms) or isolated 4-20 mA (250 ohms) Signal follower: bias and gain 2 programmable open collector outputs Analog monitor output: 0-10 VDC proportional to output frequency or output current Approx. 400 parameters & monitors Digital pulse train input (33 kHz max.) Cooling fan controlled by drive run/stop RS-422/485 MODBUS 115 kbps UL recognized electronic overload MTBF 28 years Built-in Dynamic Braking Transistor NEMA 1 enclosure Side-by-Side mounting Application Presets Maintenance monitors Service Conditions Ambient service temperature: -10° to 40°C (14° to 105°F) NEMA 1 -10° to 50°C (14° to 122°F) Open Chassis Ambient storage temperature: -20° to 60°C (-4° to 140°F) Humidity: to 95% non-condensing Altitude: to 3300 ft; higher by derating Service factor: 1.0 Input voltage: -15% to +10% 200 to 240 VAC, 380 to 480 VAC Input frequency: +/-5%; 50/60 Hz Input Phase sequence insensitive Standards UL 508C (Power Conversion) CSA 22.2 No. 14-95 (Industrial Control Equipment) UL, cUL listed; CE marked RoHS compliant EN 50178 (LVD) EN 50081-2, EN 50082-2 (EMC) EN 954-1, Category 3 Safety Standard EN 61800-3 IEC 529, 146 FCC CFR 47 Part 15 Subpart B (w/ External Filter) TUV Control Methods: (1) V/f Mode, (2) Open Loop Vector Mode THANK YOU FOR YOUR TIME & CONSIDERATION. ANY & ALL QUESTIONS WILL BE ANSWERED IN A PROMPT & THOROUGH MANNER.
