Z-COMM PLL 3545MHz-3555MHz, PSA3550C, PLL Package, US $12.00 – Picture 0
Z-COMM PLL 3545MHz-3555MHz, PSA3550C, PLL Package, US $12.00 – Picture 0

Z-comm Pll 3545mhz-3555mhz, Psa3550c, Pll Package

US $12.00

  • Potomac, Maryland, United States
  • Jan 29th
Open on mobile:
QR code
This is one piece of New Z-COMM PLL (Phase Locked-Loop) Module, 3545MHZ to 3555MHZ, Part Number: PSA3550C in PLL-24H Package (0.865"x0.605"x0.14"). PLL Internally using Analog Devices AD4106 Frequency Synthesizer IC. General Spec: Frequency Range: 3545MHz to 3555MHz; Referecne Frequency Input: 5MHz to 100MHz Phase Noise: -107dBc/HZ at 10KHz offset; Sideband Spurs: -70dBc; Output Power: 0dBm; Load Impedance: 50 Ohms; Step Size: 1000KHz; Charge Pump Output Current: 2500uA Switching Speed: 2.5ms; Startup Lock Time: 2ms; Operating Temp: -40C to +85C; Supply Voltage: 5V/24mA; Package: PLL-24H Data Sheet: http://www.rfbayinc.com/upload/files/data_sheet/ic/psa3550c.pdf http://www.analog.com/static/imported-files/data_sheets/ADF4106.pdf http://www.zcomm.com/PDFs/appNotes/AN-202.pdf
