Z-Comm RF Voltage Controlled Oscillator VCO Assembly, 2270-2360 MHz, Low Noise, US $29.95 – Picture 0
Z-Comm RF Voltage Controlled Oscillator VCO Assembly, 2270-2360 MHz, Low Noise, US $29.95 – Picture 0

Z-comm Rf Voltage Controlled Oscillator Vco Assembly, 2270-2360 Mhz, Low Noise

US $29.95

  • Morgan Hill, California, United States
  • Jul 8th
Open on mobile:
QR code
You are buying one Z-Communications (MFG PN: V800ME05-LF) RF Voltage Controlled Oscillator VCO Evaluation Development Board Assembly, 2270-2360 MHz, Low Noise, Rugged Male SMA output connector. Specifications: MFG: Z-Communications (Z-Comm) MFG PN: V800ME05-LF Frequency Range [MHz]: 2270-2360 Min. Tuning Voltage [V]: +0.5 Max. Tuning Voltage [V]: +4.5 Min. Output Power [dBm]: -2 Max. Output Power [dBm]: +8 Min. Sensitivity [MHz/V]: 47 Harmonics, worst case [dBc]: -16 Pulling [MHz] into a 14 dB Return Loss: 14 Pushing [MHz/V]: 3 Phase Noise @ 10 kHz [dBc]: -97 Temperature Range [deg C]: 0 to +70 Vcc [Vdc]: +5V Icc [mA]: 12 mA (typical) Package Size: 0.5” x 0.5” 0.22” If you are interested in just purchasing the PCB then please see link: https://www.ebay.com/itm/133783662249 If you are interested in just purchasing a PCB kit (i.e. PCB and connectors) the see link: https://www.ebay.com/itm/144068225756
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Mounting Style Surface Mount
MPN V800ME05-LF
Type Voltage Controlled Oscillator
Brand Z-Comm
Oscillator Frequency 2270 MHz - 2360 MHz
