Zbl-r620 Concrete Rebar Locator Scanner Covermeter/ Ferromagnetic Objects Finder

US $701.80

Shanghai, China
Jan 30th

Open on mobile:
QR code

ZBL-R620 CONCRETE REBAR LOCATOR SCANNER COVERMETER/ FERROMAGNETIC OBJECTS FINDER BRAND NEW PULL GAUGE TESTER EXTERNAL SENSOR FORCE METER 5000N PUSH DIGITAL 5KN DIAMOND&MOISSANITE DUAL MIZAR TESTING 2IN1 2 IN 1 TOOL JEWELRY TESTER TEST LASER DISTANCE METER GM40D 40M VOLUME TESTER RANGE FINDER PHOTOELECTRIC MEASURE BRAND NEW MEASURE GAUGE CURRENT ELECTRICAL TESTER FLUKE T5-1000 1000 VOLTAGE Introduction: The ZBL-R620 Rebar Locator is a portable, quick and easy-to-use instrument for inspecting reinforcing bars in concrete. The Rebar Locator generates a magnetic field and measures any change induced by presence of the magnetic material. The magnitude of this change is indicated on the instrument meter, which has been calibrated to read directly in diameter and depth of the bar. The use of the instrument is not restricted to inspecting reinforcing bars, but any magnetic material and ferromagnetic objects. Applications: 1. Determine the location, depth, diameter and orientation of tendons in prestressed concrete. 2. Measure the concrete cover. 3. Detect location of tendon splices and broken ends, etc. in prestressed concrete. 4. Detect the location of pipes conduit, flues, ducts and manhole covers and any other ferromagnetic objects. Specifications: 1. Uni-probe with two detects range: The Uni-probe has both a small and large detect range. 2. Detect closely located bars: Can detect bars which are closely adjacent to one another with 1.5 diameter gap. 3. Detection of rebar diameter range: ?6mm to ?32mm (0.24in-1.26in). 4. The detected rebar diameter range depends on the depth of the rebar. Diameter ?(mm) 6 8 10 12 14 16 18 20 22 25 28 32 36 40 50 Depth(mm) SmallRang min 8 6 8 8 9 9 10 10 10 10 10 12 12 14 16 max 72 76 80 82 84 84 86 86 86 90 90 90 90 90 90 LargeRang Min 8 10 12 13 14 15 16 18 18 18 20 22 24 26 28 max 100 118 126 130 144 146 148 160 162 162 172 180 180 180 180 Detection of Thickness Range of Cover Concrete: 10mm to 130mm(0.39in~5.12in). Depends on the Rebar Diameter. Diameter ?(mm) 6 8 10 12 14 16 18 20 22 25 28 32 Thickness(mm) min 8 12 12 14 14 16 16 18 18 20 22 22 max 60 62 66 68 68 72 72 74 74 76 76 80 Accuracy of Cover Thickness: Depends on the cover thickness. Cover Thickness(mm) Small Range 6~59 60~69 70~90 Larger Range 8~79 80~119 120~180 Accuracy(mm) ±1 ±2 ±4 Power Source: 6pieces AA (R6P/LR6)1.5V dry batteries. Battery Life: 32 hours continuous operation. Memory Capacity: Can store data for 1000 objects, 256 measured values for one object max. Data Transfer: 1 USB port. Analysis software: Based on Microsoft Windows, can export Detect Report in Microsoft Office Word format automatically. Operating Weight (including probe): 0.75kg (1.7lb). Weight including Carrying Case: 4.5kg (10lb). Operating Temperature Range: -10°C to 40° (14°F to 104°F). slbz uwhu upbp UAC Buyer should pay within 7 days after purchase. We only accept payment via PayPal. Our team focuses on providing high quality products with reasonable price and tries its best to keep transactions as simple as possible. Please be confident of and enjoy your shopping here! Please feel free to contact us via eBay message system or email.
