Zeroplus Lap-c 322000 32-channel Logic Analyzer Logic Cube

US $130

  • Seattle, Washington, United States
  • Jan 29th
Open on mobile:
QR code
Specifications Sample Rate   Internal Clock (Timing Mode) 100Hz~200MHz External Clock (State Mode) 100MHz     Threshold Voltages   Bandwidth:75MHz Working Range: -6V~+6V Accuracy: ±0.1V     Memory   Memory :64Mbits Depth(Per Channel) :2Mbits (Max 512Mbits for compression)     Trigger   Condition: Pattern/Edge Trigger Channel : 32 CH Post Trigger: YES Trigger Level: 1 Level Trigger Count: 1~65535     Software Functions   Data Compression : Max 2M bits x 256, Available 24CH Time Base Range : 5ps~10Ms Language : Chinese (Traditional/Simplified) English Maximum Trigger Page : 8192 Pages Waveforrm Data Display Filter&Filter Delay Trigger Delay Unlimited lncreasing Bar Automatic Attaching Bar Automatic Software Upgrade Data Statistic Auto-Save Filter Bar Protocol Analysis Protocol Packet List File Export Data Contrast Latch Function Protocol Analyzer Trigger: parallel, serial Pulse Width Trigger Module : free     Other   Power :USB (DC 5V, 500mA) Operating System: Windows 2000 / XP(32bits) / Vista / Win 7 Phase Errors: < 1.5ns Maximum Input Voltage: ±30V Impedance:500K?/10pF Safety Certification: FCC / CE / WEEE / RoHS / REACH     Extending Channel Capture   Channel mode: LAP-C(322000) + LAP-C(322000) => Channel = 62CH, Memory = 2Mbits Memory mode: LAP-C(32128) + LAP-C(32128) => Channel = 31CH, Memory = 256Kbits     Double Mode   Channels:16 channels RAM Sizes:4M     Electric Specification Item Min Typical Max Working Voltage DC 4.5V DC 5V DC 5.5V Current at Rest – – 200mA Current at Work – – 400mA Power at Rest – – 1W Power at Work – – 2W Error in Phase Off - 1.5ns – + 1.5ns Vinput of Testing Channels - DC30V – + DC30V Vreference - DC6V – + DC6V Impedance – 500K?/10pF – Working Temperature 5 °C – 70 °C Storage Temperature -40 °C – 80 °C
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand Zeroplus
Model LAP-C 322000
