Zevatech Esec Micron 2 Multi-chip Bonder Component Pick And Place Machine

US $7,200.00

Waterford, Michigan, United States
Jan 30th

Open on mobile:
QR code

DESCRIPTION Zevatech Chip Bonder / Pick and Place Part # Micron 2 Year: 1998 Product Condition: USED - Unit was installed, professionally inspected and calibrated (spent over $23,000) for a program that never launched. Comes complete with all manuals, software, and training documents. Poly Cover has a crack. Specifications: Dimensions: 77"(W) x 60"(D) x 65"(H) Weight: 3100lbs Voltage Power: 200,208,220,380,400,415 & 440 VAC Tolerance: ±10% Phase: 3 Frequency: 50/60hz Compressed Air: 87-145 PSI Vacuum: .75 Bar Environmental Conditions: 50-86°F Noise Level: 75dBA Placement Accuracy: X,Y: 0 Placement Repeatability: X,Y - ±9 Placement Repeatability: Z - ±9 Reliability:MTBF 500 Hours Reliability: MTBA 4 Hours Reliability: MTTA 1 Minute Reliability: Availability - 95% Reliability: Yield- 99.8% Placement Rate: Up to 2000 UPH Components Dimensions Min: .25x.25x.10mm Components Dimensions Max: 30x30x22mm Component Types: Flip Chips, Bare Dies, Standard SMD Components Adept System Controller VMEBus Based Controller Motorola 68060 CPU, 15mb RAM Data Base Management System XY Gantry Positioning System Precision Cartesian Mechanism Ceramic Beams Granite Base X/Y Air Bearings X/Y Linear Motors Glass Scale Linear Encoders Wear Free Design Extremely Stable Over Variable conditions and Time LZRZ Head Servo-driven Z and 0 Axes Accurarte Position Control Accurate Force Control Minimal Tilit-induced XY Error Camera Focus Height = Nozzle Tip Height Resolution: Z - 1um Speed: Z - .65ms Acceleration: Z - 15m/s2 Stroke: Z -12 to 82 mm (From substrate surface) Programmable Placement Force Min: 2N Programmable Placement Force Max: 20N Programmable Placement Force Repeatability: ±0.2N Programmable Placement Force Accuracy: ±0.2N Dovetail Plate Capacity: 20 Slots Slot Pitch: 1.25" Dispenser Accura 9 Time/Pressure Dispenser Time Pressure Valve Various Shower Nozzle Patterns Variety of Needles Auto Pressure Compensating Device Calibrations Fixture (X,Y,Z Needle Calibration) Substrate Height Measurement By Touch Probe Purge Plate Dispense Volume: .0005ml Dispense Time: .001-100 Seconds Material Viscosity: 1000-200,000cp Memory Storage: up to 16 programs Intgraded Barrel Sizes: 3,5,10,30 & 50 ml Needle Position Accuracy X,Y,Z ±: 100um Touch Probe Resolution: 5um Interface: RS232 -------------------------------------- Local Pickups Local pickup is available for all items Monday thru Friday 8:30am - 4:30pm Domestic Shipments Domestic shipments are sent via UPS or USPS Priority Service. We choose the fastest most economic shipping method based on a items size, weight, and value ratio. Items sent to Alaska & Hawaii are subject to additional charges. International Shipments We ship to all international countries. International shipments are sent USPS International Priority unless otherwise requested. Contact us for international shipping quotes. Freight Shipments Items requiring freight will be securely strapped to a pallet and loaded at no additional charge. Carriers assess an extra charge if delivery is made to residential area and/or if the service of a lift gate are required. Rigging charges may apply to items requiring special loading/shipping requirements. Your satisfaction is our highest priority! To the best of our knowledge the item is in perfect working condition. We do our very best to describe items as accurately as possible and in no way would misrepresent or knowingly sell an item that was not working. But since this item is used and at times, we do not know the history of an item, all items are sold "AS-IS". No refunds, returns, or exchanges will be given. Please contact us with any and all questions as your satisfaction is our highest priority.
