Zh4100d 30kw Diesel Generator With Diesel Engine And Brush Alternator For Power

US $3,999.99

shanghai, China
Aug 27th

Open on mobile:
QR code

ZH4100D 30kw Diesel Generator with Diesel Engine and brush alternator for power Specifications: Certification: CE Origin: CN(Origin) Speed: 1500/1800 Frequency: 50Hz/60Hz is_customized: Yes Model Number: HR30kw Rated Power: 30kw Output Type: AC Three Phase Rated Voltage: 220/380V,230/400V,110/220V Rated Current: 60A Cooling style: water cooling by radiator usage: generator or fixed power Fuel: diesel Cylinder: Multi-cylinder Cold Style: water-cooled Start: Electric Start Color: as client's requiremnets Warranty: 1 years or 1500hours Place of orign: Weifang city After-sales service: Engineers available to service Diesel generator set Generator Model : HR-30GF Rated Voltage (V): 400/230 Frequency: 50Hz/60Hz Power factor: 0.8 Type : 3P 4W Prime Power (kW/kVA): 30/37.5 Standby Power (kW/kVA): 33/41.3 Packaged Size(mm): 1900 x 740 x 1200 Gross weight:750kg Diesel Engine Data Engine Model: ZH4100D diesel engines Manufacturer : Weifang Cylinder No: 4L Cylin der arrangement: In-line , Direct injecting combustion chamber Cycle: Four stroke Aspiration: Naturally Compression ratio: 17:01 Bore * Stroke: 100 mm * 115mm Displacement: 3.26 litres Direction of rotation: Clockwise viewed from front Rated power (kw/kva): 30.1/37.63 Governor Type: Mechanical Lub oil Capacity (L): 10 Rated Fuel Consumption (L/h): 7.5 Specifications of Main Parts 1500RPM 50HZ Oil Pump type : Single grade gear type Displacement /Speed (L/min/r/min): 62/2800 Water Pump type : Centrifugal type Speed (r/min): 2800 Fuel injection pump type: Ain-line plunger type Governor model : RSV full range type Various temperature and pressure range 1500RPM 50HZ Lub oil temperature : 95 Outlet cooling water temperature : 90 Lub oil pressure : 0.3~0.5MPa 0.01MPa , when at idling speed Fyel injection pressure: 20+1.0MPa Fuel Consumption 1500RPM 50HZ 100%( Prime Power) Load: 218 g/Kw.h 75%(Prime Power) Load: 207 g/Kw.h 50%(Prime Power) Load: 220 g/Kw.h Alternator Data Brand : Brushless / brush alternator Model: HJI-30 Rated Power(kw/kva): 30/37.5 Connecting Type: 3 Phase and 4 Wires, “Y” type connecting Number of Phase: 3 Number of Bearing: 1 Power Factor: 0.8 Protection Grade: IP23 Altitude: 1000m Exciter Type: Brushless, self-exciting Insulation Class, Temperature Rise: H/H Telephone Influence Factor (TIF): 50 Voltage Regulation, Steady State: ±1% THF: 2% Alternator Efficiencies: 88.20% Shipping Ship to worldwide. All of item ship from china Directly by Register Airmail With Online Tracking Number,Generally It takes 10-20 To Most Part Of the World, But Worst Of The Case Takes 20-35 Days. Shipping And Insurance Fee Is NOT NEGOTIABLE. After Received The Payment Your Iem Will Normally Be Despatched Withing 2-5 Days ( Within Business Days). Once The Item Has Been Sent, It Will A Conformation + tracking number to your paypal email. Return 30 days money back, buyer pays return shipping Buyer is responsible for the shipping fee of warranty service No matter what reason if the item(s) return to me. Buyer need to pay shipping and insurance fee again for re-ship the item(s) except seller write the wrong shipping address, please make sure your PayPal shipping address is correct. Once your item(s) arrives in satisfactory condition. Please leave feedback for me. My feedback system will do the same for you automatically. Customer Service Please give us the opportunity to resolve any problem. We understand the concerns and frustrations you might have, and will try our best to resolve the issues. Please email us before leaving any negative feedback or low DSR ratings. We care about our valued customers, and will always try to help you. So if you have any problems, please e-mail us immediately.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	ZH4100D
Phase	three
Power Source	Diesel
Brand	Industrial power
MPN	Does Not Apply
UPC	8900007494678
