100 pcs/lot IC 74HC595RM13TR, 8-bit shift register with output latches (3-state), US $19.00 – Picture 0
100 pcs/lot IC 74HC595RM13TR, 8-bit shift register with output latches (3-state), US $19.00 – Picture 1
100 pcs/lot IC 74HC595RM13TR, 8-bit shift register with output latches (3-state), US $19.00 – Picture 0
100 pcs/lot IC 74HC595RM13TR, 8-bit shift register with output latches (3-state), US $19.00 – Picture 1

100 Pcs/lot Ic 74hc595rm13tr, 8-bit Shift Register With Output Latches (3-state)

US $19.00

  • Shenzhen, China
  • Jan 29th
Open on mobile:
QR code
                           8-bit shift register with output latches (3-state) Features • High speed: fMAX = 59 MHz (typ.) at VCC = 6 V • Low power dissipation: ICC = 4 ?A (max.) at TA= 25 °C • High noise immunity: VNIH = VNIL = 28% VCC (min.) • Symmetrical output impedance: – |IOH| = IOL = 6 mA (min.) for QA to QH – |IOH| = IOL = 4 mA (min.) for QH’ • Balanced propagation delays: tPLH ? tPHL • Wide operating voltage range: VCC (opr.) = 2 V to 6 V • Pin and function compatible with 74 series 595 • ESD performance – HBM: 2 kV – MM: 200 V – CDM: 1 kV Applications • Automotive • Industrial • Computer • Consumer Description The M74HC595 device is a high speed CMOS 8-bit shift register with output latches (3-state) fabricated with silicon gate C2MOS technology. This device contains an 8-bit serial in, parallel out shift register that feeds an 8-bit D-type storage register. The storage register has 8 3-state outputs. Separate clocks are provided for both the shift register and the storage register. The shift register has direct overriding clear, serial input, and serial output (standard) pins for cascading. Both the shift register and storage register use positive edge triggered clocks. If both clocks are connected together, the shift register state will always be one clock pulse ahead of the storage register. All inputs are equipped with protection circuits against static discharge and transient excess voltage.
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand STMicroelectronics
IC Package SOIC16_39MM
Model GoJGo.com-10273
Category Logic IC, 74 serial
MPN 74HC595RM13TR
