5 pcs/lot C8051F120-GQR, Mixed Signal ISP Flash MCU Family, US $38.00 – Picture 0

5 pcs/lot C8051F120-GQR, Mixed Signal ISP Flash MCU Family, US $38.00 – Picture 1

5 Pcs/lot C8051f120-gqr, Mixed Signal Isp Flash Mcu Family

US $38.00

Shenzhen, China
Jan 29th

Open on mobile:
QR code

Analog Peripherals - 10 or 12-bit SAR ADC • ± 1 LSB INL • Programmable Throughput up to 100 ksps • Up to 8 External Inputs; Programmable as Single- Ended or Differential • Programmable Amplifier Gain: 16, 8, 4, 2, 1, 0.5 • Data-Dependent Windowed Interrupt Generator • Built-in Temperature Sensor - 8-bit SAR ADC (‘F12x Only) • Programmable Throughput up to 500 ksps • 8 External Inputs (Single-Ended or Differential) • Programmable Amplifier Gain: 4, 2, 1, 0.5 - Two 12-bit DACs (‘F12x Only) • Can Synchronize Outputs to Timers for Jitter-Free Waveform Generation - Two Analog Comparators - Voltage Reference - VDD Monitor/Brown-Out Detector On-Chip JTAG Debug & Boundary Scan - On-chip debug circuitry facilitates full-speed, nonintrusive in-circuit/in-system debugging - Provides breakpoints, single-stepping, watchpoints, stack monitor; inspect/modify memory and registers - Superior performance to emulation systems using ICE-chips, target pods, and sockets - IEEE1149.1 compliant boundary scan - Complete development kit 100-Pin TQFP or 64-Pin TQFP Packaging - Temperature Range: -40°C to +85°C High Speed 8051 ?C Core - Pipelined Instruction Architecture; Executes 70% of Instruction Set in 1 or 2 System Clocks - 100 MIPS or 50 MIPS Throughput with On-chip PLL - 2-cycle 16 x 16 MAC Engine (C8051F120/1/2/3 and C8051F130/1/2/3 Only) Memory - 8448 Bytes Internal Data RAM (8k + 256) - 128k or 64k Bytes Banked FLASH; In-System programmable in 1024-byte Sectors - External 64k Byte Data Memory Interface (programmable multiplexed or non-multiplexed modes) Digital Peripherals - 8 Byte-Wide Port I/O (100TQFP); 5V tolerant - 4 Byte-Wide Port I/O (64TQFP); 5V tolerant - Hardware SMBus™ (I2C™ Compatible), SPI™, and Two UART Serial Ports Available Concurrently - Programmable 16-bit Counter/Timer Array with 6 Capture/Compare Modules - 5 General Purpose 16-bit Counter/Timers - Dedicated Watchdog Timer; Bi-directional Reset Pin Clock Sources - Internal Precision Oscillator: 24.5 MHz - Flexible PLL technology - External Oscillator: Crystal, RC, C, or Clock Voltage Supples - Range: 2.7-3.6V (50 MIPS) 3.0-3.6V (100 MIPS) - Power Saving Sleep and Shutdown Modes

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	SILICON LABS
IC Package	TQFP100
Model	GoJGo.com-10580
Category	MCU
MPN	C8051F120-GQR
