1pcs Spk-8635-b Bluetooth Audio Receiver Module Mp3 Decoder And Card Reader

US $32

shenzhen, China
Jun 9th

Open on mobile:
QR code

Product Name: SPK-8635-B Bluetooth Audio Receiver Module MP3 Decoder And Card Reader More Items In Our Store,Click Here! SKU: 2379 Parsts No. : Package: Brand: Quantity: 1 1. Module Introduction SPK-8635-B Bluetooth stereo audio module uses English CSR's main chip design. High integration, small size, superior sound quality and other characteristics, with only a few external components will be able to achieve its powerful features. can establish a connection with any Bluetooth audio equipment which have A2DP?AVRCP transmission and remote control protocol?such as: mobile phones, Bluetooth stereo audio transmitter module, Bluetooth adapter has Bluetooth, etc.).Receive high-quality stereo wireless audio streaming, and can achieve remote control for audio player. Size and pin definitions SPK-8635-B compatible BC05-B, users can upgrade the product without any changes of the premise, thus shortening the product development time. 2. Module characteristics 1). Built-in high-quality DAC conversion circuit: SNR 95dB. 2). Kalimba DSP data processor embedded powerful, complete all kinds of digital speech processing. 3). Small size: 15x21mm, compatible with all the product structure. 4). Higher Bluetooth version: Bluetooth V4.0, high software compatibility. 5). Extremely low power consumption: Operating current is less than 2mA. 6). Very far transmission distance: RF Class2 power levels of up to 20 m above. 7). With high-quality audio transmission protocol: A2DP1.2, AVRCP1.4 remote control protocol. 8). Have HFP V1.6 agreement. 9). Support Simple Pairing. 10). Support AUX input. 3.Module applications 1). All kinds of high-quality Bluetooth stereo speakers,sound. 2). All kinds of high-quality Bluetooth wireless stereo audio receiving device. 4. Module pin definition and package size 5.Module pin functions in detail 6. Typical Application Circuit 7. LAYOUT Notes 1). when placing modules: antenna below (including PCB back) and around can not have any traces and devices,the antenna should be placed in the open without shelter place in order to ensure the best performance of antenna. 2). To ensure the integrity of the ground, we recommend a large area paved, multi-punched. Since Bluetooth to work in the high-frequency band, poor grounding will bring the current sound.All the network with the main power supply ground wire as a reference point, please. Any problem, please contact us freely 1) We accept PayPal payment ONLY. inkfrog terapeak inkFrog Analytics

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	SPK-8635-B
Country of Manufacture	Does not apply
Model	SPK-8635-B
UPC	Does Not Apply
MPN	SPK-8635-B
Country/Region of Manufacture	China
