1x Brand New Atmel At32uca1512 32-bit Micro-controller Adapter Ready To Use

US $23.00

San Jose, California, United States
Jan 29th

Open on mobile:

NOT SOLD TO CALIFORNIA BUYERS. PLEASE DO NOT BID IF YOU'RE FROM CA. SORRY! Listed is a BRAND NEW AT32UCA1512 Atmel micro-controller with a lot of built-in peripherals, e.g., ethernet, etc. It is soldered on the TQFP100-to-PDIP adapter board and is ready to use. I soldered in the female headers. The headers have some minor not straight edges came from the extra header holes that are not used, but that's nothing to worry about and are barely seen. All pins are connected to female headers, and each pin is fully associated to a female header hole. Visit Atmel for FREE compilers, sample appnotes, example applications, etc. TERMS No returns or refunds because this is electronics/microchip. I am not responsible in any way of your own experiments or projects with this micro-controller. Sorry I cannot provide technical support. Click on the below for the datasheet. Datasheets AT32UC3Azzzz Manual AT32UC3A0/A1 Summary Product Training Modules AVR UC3 Audio Application MCU Product Line Introduction AVR® UC3 Introduction Software Framework (ASF) Example of Use Studio Introduction to Software Framework (ASF) Studio Development Environment Overview Part 1 Standard Package 1 Category Integrated Circuits (ICs) Family Embedded - Microcontrollers Series AVR®32 UC3 A1 Core Processor AVR Core Size 32-Bit Speed 66MHz Connectivity Ethernet, I?C, SPI, SSC, UART/USART, USB OTG Peripherals Brown-out Detect/Reset, POR, PWM, WDT Number of I/O 69 Program Memory Size 512KB (512K x 8) Program Memory Type FLASH EEPROM Size - RAM Size 64K x 8 Voltage - Supply (Vcc/Vdd) 1.65 V ~ 3.6 V Data Converters A/D 8x10b Oscillator Type Internal Operating Temperature -40°C ~ 85°C Package / Case 100-TQFP Supplier Device Package 100-TQFP Other Names AT32UC3A1512-AURCT Features • High Performance, Low Power 32-Bit Atmel® AVR® Microcontroller – Compact Single-cycle RISC Instruction Set Including DSP Instruction Set – Read-Modify-Write Instructions and Atomic Bit Manipulation – Performing 1.49 DMIPS / MHz Up to 91 DMIPS Running at 66 MHz from Flash (1 Wait-State) Up to 49 DMIPS Running at 33MHz from Flash (0 Wait-State) – Memory Protection Unit • Multi-hierarchy Bus System – High-Performance Data Transfers on Separate Buses for Increased Performance – 15 Peripheral DMA Channels Improves Speed for Peripheral Communication • Internal High-Speed Flash – 512K Bytes, 256K Bytes, 128K Bytes Versions – Single Cycle Access up to 33 MHz – Prefetch Buffer Optimizing Instruction Execution at Maximum Speed – 4ms Page Programming Time and 8ms Full-Chip Erase Time – 100,000 Write Cycles, 15-year Data Retention Capability – Flash Security Locks and User Defined Configuration Area • Internal High-Speed SRAM, Single-Cycle Access at Full Speed – 64K Bytes (512KB and 256KB Flash), 32K Bytes (128KB Flash) • External Memory Interface on AT32UC3A0 Derivatives – SDRAM / SRAM Compatible Memory Bus (16-bit Data and 24-bit Address Buses) • Interrupt Controller – Autovectored Low Latency Interrupt Service with Programmable Priority • System Functions – Power and Clock Manager Including Internal RC Clock and One 32KHz Oscillator – Two Multipurpose Oscillators and Two Phase-Lock-Loop (PLL) allowing Independant CPU Frequency from USB Frequency – Watchdog Timer, Real-Time Clock Timer • Universal Serial Bus (USB) – Device 2.0 Full Speed and On-The-Go (OTG) Low Speed and Full Speed – Flexible End-Point Configuration and Management with Dedicated DMA Channels – On-chip Transceivers Including Pull-Ups • Ethernet MAC 10/100 Mbps interface – 802.3 Ethernet Media Access Controller – Supports Media Independent Interface (MII) and Reduced MII (RMII) • One Three-Channel 16-bit Timer/Counter (TC) – Three External Clock Inputs, PWM, Capture and Various Counting Capabilities • One 7-Channel 16-bit Pulse Width Modulation Controller (PWM) • Four Universal Synchronous/Asynchronous Receiver/Transmitters (USART) – Independant Baudrate Generator, Support for SPI, IrDA and ISO7816 interfaces – Support for Hardware Handshaking, RS485 Interfaces and Modem Line • Two Master/Slave Serial Peripheral Interfaces (SPI) with Chip Select Signals • One Synchronous Serial Protocol Controller – Supports I2S and Generic Frame-Based Protocols • One Master/Slave Two-Wire Interface (TWI), 400kbit/s I2C-compatible • One 8-channel 10-bit Analog-To-Digital Converter • 16-bit Stereo Audio Bitstream – Sample Rate Up to 50 KHz 32-Bit Atmel AVR Microcontroller AT32UC3A0512 AT32UC3A0256 AT32UC3A0128 AT32UC3A1512 AT32UC3A1256 AT32UC3A1128 Summary 32058KS–AVR32–01/122 AT32UC3A • On-Chip Debug System (JTAG interface) – Nexus Class 2+, Runtime Control, Non-Intrusive Data and Program Trace • 100-pin TQFP (69 GPIO pins), 144-pin LQFP (109 GPIO pins) , 144 BGA (109 GPIO pins) • 5V Input Tolerant I/Os • Single 3.3V Power Supply or Dual 1.8V-3.3V Power Supply
