2015 Optical Glass Lenses Plano-convex Lenses

US $73.13

jinan,shandong, China
Jun 9th

Open on mobile:
QR code

2015 optical glass lenses plano-convex lenses product descrition: Plano-convex lenses, the most economical transmissive focusing elements available, are ideally suited for laser heat treating, welding, cutting, and infrared radiation collection where spot size or image quality is not critical. They are also the economical choice in high f-number, diffraction limited systems where lens shape has virtually no effect on system performance. For proper performance with a plano-convex lens, the curved surface should face toward the incoming collimated beam or the longer conjugate distance (the object and image distances together are referred to as the conjugate distance). In addition to the standard focal lengths listed here, II-VI maintains an extensive inventory of test plates and tooling. This enables fabrication of many other focal lengths without additional tooling charges. Besides the plano-convex, meniscus, and aspheric lens shapes offered in this catalog, II-VI routinely fabricates biconvex and negative focal length lenses upon request. Parameter: Effective Focal Length (EFL) Tolerance ±2% Dimensional Tolerance Diameter: +0.000”-0.005” Thickness: ±0.010” Edge Thickness Variation (ETV) <= 0.002 Clear Aperture (polished) 90% of diameter Surface Figure at 0.63µm Plano: 1 fringe Power 1/2 fringe Irregularity Radius: varies depending upon radius Scratch-Dig 20-10 AR Coating Reflectivity per Surface at 10.6µm <= 0.20% Part # Description Diameter (inches) Diameter (mm) Focal Length Working Distance Edge Thickness (inches) Edge Thickness (mm) 123265 ZnSe 0.50 12.7 1.0” - 0.060 1.52 379095 ZnSe 0.75 19.05 1.0” - 0.085 2.16 104370 ZnSe 1.0 25.4 2.5” - 0.085 2.16 614868 ZnSe 1.0 25.4 5.0” - 0.102 2.59 949585 ZnSe 1.0 25.4 10.0” - 0.111 2.82 696289 ZnSe 1.1 27.94 2.5” - 0.085 2.16 561067 ZnSe 1.1 27.94 5.0” - 0.160 4.06 774048 ZnSe 1.1 27.94 7.5” - 0.106 2.69 982910 ZnSe 1.1 27.94 10.0” - 0.109 2.77 803557 GaAs 1.5 38.1 2.5” - 0.0799 2.03 101766 ZnSe 1.5 38.1 2.5” - 0.300 2.62 975597 GaAs 1.5 38.1 3.5” - 0.354 8.99 441406 ZnSe 1.5 38.1 3.75” - 0.086 2.18 941031 ZnSe 1.5 38.1 - 5.0” 0.280 7.11 578662 ZnSe 1.5 38.1 5.0” - 0.300 7.62 464497 ZnSe 1.5 38.1 - 7.5” 0.280 7.11 306068 ZnSe 1.5 38.1 7.5” - 0.300 7.62 892020 ZnSe 2.0 50.8 7.5” - 0.310 7.87 232771 ZnSe 2.0 50.8 7.5” - 0.380 9.65 236670 ZnSe 2.5 63.5 10.0” - 0.390 9.90 About us: We have been in the Industrial and manufacturing supply field for over 13 years and take pride in providing our customers with THE BEST CUSTOMER SERVICE. High quality products, competitive price and good service are our guidance contact us We do our best to describe everything. If you have any questions, please feel free to email us. we will go though all the problem to assist you.
