3.2" Tft Lcd Display Touch Panel /w Sd Card Slot Module For Arduino

US $270

Shanghai, China
May 31st

Open on mobile:
QR code

3.2" TFT LCD Display touch panel /w SD card Slot Module for Arduino Description The 3.2” inch TFT LCD module integrated a ILI9341 TFT LCD controller and ADS7843 compatible touch screen controller as well as a SD card cage. It is suitable for embedded systems which require display high quality colorful image or video with interactive control and storage purpose. The Module interfaces to microcontrollers via a 2*20 Pin 2.54mm dual row pin header interface , can easily be connected to any microcontroller or FPGA and DSPs. Features: LCD Module is with ILI9341 Controller ADS7843 compatible touch panel controller Standard SD card cage Support 16 bit RGB565 format , can connect any 16 bit data bus Onboard 3.3V regulator require a single 5V supply 3.3V I/O voltage level tolerance Module Size (L * W * H): 94 * 64 * 14mm including connector Pin Definition: 1 GND 21 LCD_DB0 2 VCC 22 LCD_DB1 3 N.C. 23 LCD_DB2 4 LCD_RS 24 LCD_DB3 5 LCD_WR 25 LCD_DB4 6 LCD_RD 26 LCD_DB5 7 LCD_DB8 27 LCD_DB6 8 LCD_DB9 28 LCD_DB7 9 LCD_DB10 29 TouchP_CLK 10 LCD_DB11 30 TouchP _CS 11 LCD_DB12 31 TouchP _DIN 12 LCD_DB13 32 TouchP _BUSY 13 LCD_DB14 33 TouchP _OUT 14 LCD_DB15 34 TouchP _Penirq 15 LCD_CS 35 SD_OUT 16 N.C. 36 SD_SCK 17 LCD_RESET 37 SD_DIN 18 N.C. 38 SD_CS 19 LED_BL 39 N.C. 20 N.C. 40 N.C. Download: www.uctronics.com/download/lcd/3.2tft-(ssd1289).zip Package including: 1pcs 3.2" TFT LCD Display touch panel /w SD card Slot Module for Arduino Payment We accept Paypal as payment Delivery details Delivery to most of the countries will take 2-4 weeks, if there's no problem when pass through the customs. Please make sure your shipping address is correct.Any non-received items caused by invalid or wrong shipping address are not in our full refund or replacement policy. The extra fee occured when the product pass through the customs should be paid by buyer Terms of sales The default shipping is by China Post air mail/Hongkong air mail to worldwide. We provide you combine shipping by e-Packet Service to USA and only charge you 1.8USD for each order. Item will be shipped within 1-2 working days after your cleared payment.Note:order more than $50, we provide free tracking number, order less than $60, customer need to pay $2 if need tracking number. About us We are a company based in China developing and manufacturing electronic development device , including electronic components ,camera module, camera lens , LCD modules and other development board for Raspberry pi,Arduino and other opensource hardware Platform We can also provide customized design and manufacture services according to your requirements. Contact us If you have any questions, please feel free to leave us ebay message or email us directly! On May-18-16 at 12:16:46 PDT, seller added the following information:
