3axis Cnc Controller Kit Nema23 Cnc Stepper Motor 76mm 3a 270oz-in &driver&power

US $170.00

???, ???, China
Jan 29th

Open on mobile:
QR code

Package include: 3 x CW5045 stepper motor driver 3 x 23HS8430 stepper motor 1 x 350W 36V/9.7A switching power supply 1 x 5 axis breakout board V5 type 1 x DB25 parallel cable 1 x USB cable English user manual for breakout board and stepper motor driver will send by email. 1. 5 axis breakout board It can most connection 5pcs driver and control 5pcs motor in the same time It is with 4-wire limit switch to insure our safty movement It is with relay port to contro the cnc spindle Working voltage is 5VDC and support with MACH3,EMC2,KCAM4 software Size:9x5.7cm 2. CW5045 high microstep stepper motor driver DC power input type:24V~50VDC; Output current:1.3A-4.5A; Mircostepping:1(1.8?),1/2,1/4,1/8,1/16,1/32,1/64,1/128,1/256;1/5,1/10,1/25,1/50,1/125,1/250; Protect form : Overheated protect, lock automatic half current ,error connect protect; Working environment:Temperature-15-40deg Humidity<90%; It is fit for NEMA17-23 two and four phase stepper motors whose current is small than 4.5A,it also can fit for small length NEMA34 two and four phase stepper motors. 3. Stepper Motor General Specification: Step angle accuracy:+ - 5%(full step,not load) Resistance accuracy: + - 10% Inductance accuracy:+ - 20% Temperature rise: 80deg Max(rated current,2 phase on) Ambient temperature ----------—20deg ---- +50deg Insulation resistance:100ohm Min,500VDC Insultion Strength--------500VAC for one minute Datasheet(23HS8430,8mm diameter shaft,21mm length ,270oz-in or 18kg.cm holding torque) Note:if you need double shaft pls contact us,we can produce. Motor lead wires: RED: A+ GREEN: A- YELLOW: B+ BLUE: B- 4.Switching power supply 350W,Input:100-120VAC or 200-240VAC,50/60Hz,Output:36v/9.7 A,single output switching power supply Shipping Please open the package and check if there are some damages before sign, if there are some damages , please do not sign and contact us immediately We ship to worldwidebut If your country’s custom is strict, please contact us before you bid to check detail and confirmed. Delievry time USA post service round 10-18 business days Canada China post round 25-40 business days Australia China post round 20-35 business days Western EU(Germany,UK,France, etc) China post 20-35 business days Asia,South America,other countries Chins post round 15-40 business days Note:above offer is default delivery way,if you need fast delivery like as DHL/UPS or post service pls inform us to confirm the shipping cost before you bid Above DHL/UPS offer is without remote fee,if your post code is remote it need extra cost. All items will be shipped within 1-3 business days upon receipt of payment Payment We accept paypal payment,all Paypal must be confirmed(shipping and billing address must match and correct and it need tell us your telephone no for delivery) Payment must be made within 48hours of the auction end time Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer responsibility. Problem&Feedback Please give us the opportunityto resolve any problem when you have,we concern your problem and we will try our best to resolve it. We are a new member in ebay now,and need understand both of sides Pls email us before you want to leave any negative feedback Refund When you have the parcel,and not satisfied the goods or it is other problem like as broken,pls tell us the detail reason and provide the photos,after confirm we will refund your money,but the delivery charge paid by buyer. Contact us Email:sale1@rattmmotor.com,MSN:tonyswj@hotmail.com Welcome worldwide customer inquire and questions,we will try to do our best to feedback customer’s email within 1-2 business days,if not pls check the mail box again Customer’s satisfaction is very important to us.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	RATTM MOTOR
Phase	2
Model	23HS8430/CW5045
Application 1	Semiconductor Equipment
MPN	http://hgauto.en.alibaba.com/
Application 2	Milling Machine, Engraver Machine
Country/Region of Manufacture	China
Application 3	CNC Routers
Holding Torque	270oz-in/ 180Ncm
Driver name	CW5045
Type	Hybrid
Driver Microstep	256 microstep
Current / Phase	3A
input voltage and current	24-50V,4.5A
Step Angle(degrees)	1.8
