3axis Cnc Router Machine Complete Kit 2.2kw Cnc Engraver Watercooled 1000*1000mm

US $1,559.19

Shenzhen, China
Aug 23rd

Open on mobile:
QR code

Store category Sign Up Now ! You may also like 2200W Water Cooled Spindle 3Axis CNC Engraver Engraving Cutting Machine 1000mm Product Description This is a culmination of all our experience, feedback, and suggestions from selling the OX CNC Machine. Based on C-Beam, V-Slot, Xtreme Solid V-Wheels and Tr8*8(P2) Lead screws it is strong, accurate and reliable. With a CNC Kit you can manufacture functional engineering parts, toys, signs, or whatever you can imagine without leaving the workshop. The Cable Drag Chain bundle contains all the hardware for mounting Cable Drag Chains Ox CNC or other CNC machine to help with cable management. NVUM 3 Axis USB Controller Bundle are perfectly used for engraving machine. The 2.2KW Water Cooled Spindle is a heavy duty router, and due to the water cooled system, is comfortably capable of running for a long time without stopping. This makes it ideal for long, complicated jobs or applications. Materials you can Mill/Cut/Carve & Engrave: Aluminum Hard Wood Soft Wood Oak Plexi Glass Delrin HDPE Foam Dimension Details: Travel (Cutting Area): – X Axis: 800mm – Y Axis: 770mm – Z Axis: 122mm (85mm cutting depth ) Workable Material Height (max): 85mm Drive System:/td> TR8x8(P2) ACME Lead Screw Machine Accuracy: 0.05mm~ 0.10mm Footprint: 1000mm x 1000mm (not including motors) Specs of Nema23 (1.26 N.m) Stepper Motor: NEMA23 Shaft Size: 1/4" Step Angle: 1.8 Holding Turque: 1.26N.m Rated voltage: 3.36A Rated current: 2.8A Specs of 2.2 kW Water Cooled Spindle: Net weight: 5.3kg Spindle Spec: φ 80 x 215 mm Power: 2.2 kW Voltage: 110 V Frequency: 400 Hz Speed: 0-24000 R/min Water Cooling Run-out off: less than 0.005 mm Grease Lubrication VFD Inverter 2.2kW 110V Collet: ER20 Sizes: 1mm, 2mm, 1/8″, 4mm, 5mm, 6mm, 1/4″, 7mm, 8mm, 9mm, 10mm, 11mm, 1/2″, 13mm PLEASE NOTE: This full kit is default to send 110V voltage of 2.2KW. This kit includes 4 x NEMA 23 Stepper Motors as standard! Part List: Screw Driven 1000x1000 Plates Item name Size Qty Y-Plate-Left T6*253.94*180 1 Y-Plate-Right T6*253.94*180 1 Y-Plate-Inner T3*180*134.86 2 Y-End-Plate-Left T6*104.8*120 2 Y-End-Plate-Right T6*104.8*120 2 X-Plate-Front T6*125*125 1 X-Plate-Back T6*125*197.5 1 Z-End-Mount-Motor T6*80*64.8 1 Z-End-Mount-Bottom T6*80*60.95 1 Z-Plate T6*125*125 1 End-Cap T3*40*20 4 Extrusions Item name Size Qty V-Slot-2040 915mm 2 995mm 2 1000mm 1 V-Slot-2080 960mm 3 Z C-Beam 250mm 1 X C-Beam 1000mm 1 Y C-Beam 1000mm 2 Motion Components Item name Size Qty Xtreme solid v wheel kit 10.2*23.9 49 X-ACME-Screw 1031mm 1 Y-ACME-Screw 1031mm 2 Z-ACME-Screw 281mm 1 Anti-Backlash Nut Block 12*33*34 1 ACME-Nut-Block T12*20*34 6 688ZZ-Bearing 8*16*5 8 Flexible-Coupler 6.35*8 4 Brackets & Spacers Item name Size Qty Angle Corner Bracket 20*20*17 8 Triple L Bracket 20*20*59.6 8 Eccentric spacer 10HEX*6 21 Aluminum Spacer 3mm 14 6mm 27 9mm 21 40mm 16 Precision-Shim T1*5.2*10 14 8mm Shim T1.58*8*12.73 8 Hardwares Item name Size Qty Lock Collar 8*14*7 8 T-nut M5 80 Nylon lock nut M5 53 Low profile screw 8mm 68 12mm 24 15mm 40 20mm 8 25mm 14 30mm 6 50mm 16 60mm 21 NEMA23-Stepper-Motor 1.26N.m 4 Drop In T Nut M5 25 Cable Drag Chain Combo 15x30 Cable Drag Chain / 3 Chain Mount / 3 M5 Nylon Nut / 9 M5 Drop In Tee Nuts / 3 Low Profile M5 8mm 8mm 9 Low Profile M5 15mm 15mm 4 Controller Combo 4 Core Shielded Cable 4 2 Core Shielded Cable 3 DC Power Cable 1 Ground Wire 1 E-Stop Switch + E-Stop Cable 1 Limit Switch Kits 3 CNC Controller - 4 Axis USB - Novusun 1 Stepper Driver - TB6600 4A 40V 4 MEAN WELL Power Supply - 4V 350W 1 2.2KW Water Cooled Spindle Combo 2.2KW Water Cooled Spindle (DIA 80mm) 1 VFD Controller 1 Spindle Mount Kit (ID 80mm) 1 75W Water Pump 1 Water Pipes 1 ER20 collet chuck set from 1 mm to 13 mm 14 NOTE: Maximum recommended speed for Lead Screws 1000mm or greater is 400RPM. Kindly Note: This Machine Not Including: MDF Working Table, Drill Bits.(available at local hardware store) Extrusions are new and M5 tapped as where it is necessary! PDF Assembly Manual is available by email. Price not included softwares, please buy it from the official website! We don't provide technical support for software debugging. * Any Mains power connections must be installed by a Licensed electrician or suitability qualified person! Z Travel Explained: To clarify the Z Travel, this is not the max cutting depth or travel range of the acuator. Z Travel is the distance dowmwards it can travel before hitting the spoiler board supports. This has two spoilerboard support configurations. One with a travel of 66mm, and a lower one with a travel of 106mm. The reason for the two configurations is that if the machine is always used to cut thin materials, for accuracy reasons it is better to have the work piece as closed to the Z-Actuator as possible, so in this case the machine should be setup in the higher 66mm travel configuration. The higher configuration has a Z travel of 66mm, with a 12mm spoiler board, this will reduce the Z travel to 54mm. In this case 54mm is maximum thickness of material that will fit on the machine. To calculate the max cutting depth for a chosen piece of material it is : Max Cutting Depth = Z travel – Material Thickness For instance a setup with a 12mm spoiler board, the max Z travel is 54mm, so when cutting into a material 30mm thick the max cutting depth would be: Max Cutting Depth = 54 – 30 = 24mm This means with a 30mm piece of material it would not be possible to cut it the whole way though. The max thickness that can be cut the whole way through is half the Z travel. So with a Z travel of 55mm, 27mm is the maximum thickness of material that could be cut the whole way through. And for the lower configuration the maximum thickness that can be cut the whole way through is 47mm. Technical Specification: &nsp; Size Frame Size Working Area 1000 x 1000mm 800 x 770mm Z Height 54mm Or 94mm Travel, 27mm Or 47mm Workable depth, with a 12mm spoilerboard. The spolierboard supports have two height configuration, these are the maximums for each configuration. Motion Drive Systerm - ACME Lead Screws Linear Guides - Polycarbonate wheels on anodised C-Beam V-Slot Extrusion. Motors - NEMA23 175oz Stepper Motors (X, Y & Z) Accuracy - 0.05 - 0.10mm Payment Delivery details feedback return policy Contact us Payment We accept PayPal payment only Payment must be received within 7 days after order is made. Fees such as import duties, taxes are not included in the item price or shipping costs. These charges are the buyer's responsibility. Delivery details NOTEThe item will be delivered by airmail ,USPS ,DPD ,DHL ,UKSHIPPING ,Since weekend and legal holiday. Please kindly allow 8-15 working days for delivery. but it varies with different countries. Occasionally, it may take a bit longer time, due to local dispatches , Customs checking, High Season period, eg. x'mas or other reasons. Your patience is always appreciated! 7-12 working days to: USA 8-12 working days to: Canada,Ireland, Austria, Belgium, Denmark, Germany, France, Finland, Luxembourg, Norway, Portugal, Sweden, Switzerland, Spain, Greece, United Kingdom 10-15 working days to: Other countries feedback We maintain high standards of excellence and strive for hundred percent customer satisfaction. Feedback is very important to us. We hope that you contact us immediately before you give neutral or negative feedback, so that we can address your concerns. It is impossible to address issues if we do not know about them! return policy Your satisfaction is our ultimate goal. We work hard to earn your trust and future business. Our certified technicians have tested each item before shipping. The unit comes with 1 year limited warranty on all manufacturing defects. a) If you receive a defective item, you may return it or ask for a discount. Please contact us within 14 days after you receive the package. b) What you returned must be intact and in its original packaging as re? u. Customer is responsible for shipping costs of the returned item. c) We will cover the cost of shipping back t with the shipping rate indicated in the registration page. We will send you a new unit or refund the full payment you paid. Thank you. Contact us Business Hour: Monday To Friday: 8:30 AM to 5:00 PM (Beijing China time) Due to time zones, our reply to your questions may not be immediately. But within above working time, we will reply your email within 24 hours. If it's non-workdays, please kindly be patient and wait till Monday. Please contact us with ebay message. Please feel free to contact us if you have any questions. On Aug-22-21 at 20:17:16 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	shipping notice	Can't not ship to Puerto Rico,Alaska/Hawaii
Drive System	Screw Driven
Brand	Unbranded
Kit Include 01	CNC Mechanical Kit 1000 x 1000mm
MPN	Does Not Apply
Kit Include 02	4pcs Nema23 Stepper Motors
Model	CNC Router Machine Complete Kit
Kit Include 03	Controller Set
Size	1000*1000mm
Kit Include 04	2.2KW Water Cooled Spindle Combo 110V
Motors	NEMA23 175oz Stepper Motors (X, Y, Z)
Kit Include 05	Cable Drag Chain Set - 3PCS
Accuracy	0.05 - 0.10mm (Screw Driven)
Frame Material	6061-T5 Aluminum
UPC	Does not apply
