8" Bison 3 Jaw "settru" Lathe Chuck + Adapter Plate

US $1,325.00

Columbus, Ohio, United States
Jan 30th

Open on mobile:
QR code

8" Bison Chuck 3 Jaw "SetTru" Fine Adj Lathe Chuck + One Adapter Plate & Chuck Package 8" Bison Chuck 3 Jaw "Set-Tru" T.I.R. 0.0004" With 4 Fine Adjustment Screws , Scroll Chuck, Forged Steel Body, 3-pinion Design. Standard Accessories: 1 full set of two-piece reversible jaws hard and master jaws. 1 Set of mounting bolts 1 Set of fine adjustment screws 2 Hex Keys 1 Wrench * Thru-Hole 2.165 * Jaws closed Min .16 - Max 3.54 * Jaws reversed Max open 7.87 * Eliminates the need for spring collets. * 4 micro adjustment screws provide 0.0004" T.I.R. repeatability. * Extremely high gripping concentricity. * 2-piece hard top & master hard jaws are American Standard Tongue & Groove. 3 Total Jaws included + 3 masters. * Chuck body made of high quality Forged steel, is safe at high lathe speeds. * Forged Scroll fully hardened with thread flanks ground on both sides for longer life and higher accuracy. * Hardened and ground bushings are pressed into the pinion seats. * 3 pinions are hardened and ground * Chuck wrench * Each chuck is balanced within fine limits. * The Life of Bison "Set-Tru" chucks is approximately 2.5 times longer than universal chucks. Bison lathe chucks are warranted by Toolmex Corpation to the original user against defects in workmanship or materials under normal use for one year afther date of purchase. Any part which is determined, by toolmex, to be defective in material or workmanship can be retrned to an authorized service location designated by toolmex, shippping cost prepaid. 8" Bison "Set-Tru" Chuck Accepts Bison Adapter Plates Only. As part of this Selling Set; Which 1 Fits Your Spindle Nose? 8" Bison "Set-Tru" A-Type Adapter plate 2 A-Type to choose one from Inside through Hole Diameter 7.87 A2-5 A2-6 Photo Below A-Type below 8" Bison "Set-Tru" D-Type Adapter plates 4 D1-Type adapters to choose one from. Inside through Hole Diameter 7.87 D1-3 # of studs 3 Stud Diameter 9/16" D1-4 # of studs 3 Stud Diameter 5/8" D1-5 # of studs 6 Stud Diameter 3/4" D1-6 # of studs 6 Stud Diameter 7/8" Photo Below D1-Types 8" Bison "Set-Tru" Threaded Adapter plates 3 Threaded Types to choose one from: Inside through Hole Diameter 7.87 1-10 1-1/2" - 8 2-3/16" - 10 2-1/4" - 8 Photo Below Threaded-Types Over 50 years of Quality European Manufacturing have made BISON the number one choice for Steel and Semi Steel Manual Lathe Chucks. Whether scroll, independent or collet, these chucks have been replacing the competitions for the last 30 years without sacrificing production. Their value is not just an exceptional price but European craftsmanship made to international specifications with ease of maintenance. Offered with direct spindle mounting or special application back plates their easy installation is recognized and appreciated in the industry. All parts are manufactured and assembled in the same plant for consistent repeatability in material and workmanship. Spare parts and jaw options are readily available eliminating excessive downtime for new product conversions and standard maintenance. When it comes time for a new chuck, BISON is the only brand to buy. SHIPPED ALL NEW BISON PRODUCT IN ORIGINAL BOX. CHUCK WEIGHT 35 lbs. AVERAGE ADAPTER PLATE WEIGHT 10 lbs. TOTAL AVERAGE CHUCK PACKAGE WEIGHT 45 lbs. TOTAL SHIPPING $25.00. 575 N. Hague Ave. Columbus, Ohio. 43204 Phone # 1-800-543-5998 After purchasing, pay instantly with your credit card through PayPal!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	Bison Workholding
MPN	7-866-0800
