A2-11 Chuck Adapter 15" Cnc Lathe Kitagawa Cb21a11 Chuck Adapter

US $500.00

Louisville, Kentucky, United States
Jan 30th

Open on mobile:
QR code

THIS AUCTION IS FOR A NEW CNC LATHE CHUCK ADAPTER PLATE A2-11. COULD BE A KITAGAWA CB21A11. SEE SPECS CHART BELOW IN RED! $$$PLEASE EMAIL OR CALL 1-812-968-5230 IF YOU HAVE ANY QUESTIONS OR SHIPPING QUOTE$$$$ SOME DIMENSIONS I HAVE VERIFIED! DRIVING STUD 1.156 X .400 DP THICKNESS 1.575 TO 10.87 DIA. STEPS DOWN TO 1.500 OUT TO 15" (6) M22 X 2.5 TAPPED HOLES 13" B.C. (6) .863 DIA. DRILL AND COUNTERBORED ON A 9.25" B.C. DIMENSIONS (Dimensions in Inches) Fig. 1 Fig. 2 ** Spindle Adapter Plates are manufactured to close tolerances and fits. These dimensions are for reference only! MODEL CB06A05 CB08A05 CB08A06 CB10A06 CB10A08 CB15A08 CB15A11 CB18A08 CB18A11 CB21A11 CB21A15 CN10A06 Spindle Nose A2-5 A2-5 A2-6 A2-6 A2-8 A2-8 A2-11 A2-8 A2-11 A2-11 A2-15 A2-6 A 5.512 6.693 6.693 8.661 8.661 11.811 11.811 14.961 14.961 14.961 14.961 7.874 B 0.591 0.866 0.669 0.984 0.709 1.299 0.866 1.299 0.866 1.614 1.063 0.787 C 3.250 3.250 4.188 4.188 5.501 5.501 7.751 5.501 7.751 7.751 11.25 4.188 D 3.138 3.138 4.055 4.055 5.354 5.512 7.563 5.512 7.563 7.563 9.921 4.055 E 0.641 0.641 0.766 0.766 0.953 0.953 1.156 0.953 1.156 1.156 1.406 0.766 F 0.256 0.256 0.256 0.256 0.315 0.315 0.394 0.315 0.394 0.394 0.394 0.256 G 4.125 4.125 5.250 5.250 6.750 6.750 9.252 6.750 9.252 9.252 13.000 5.250 H 0.472 0.433 0.531 0.531 0.669 0.669 0.827 0.669 0.827 0.827 0.945 0.531 J 4.567 5.250 5.906 6.750 7.480 9.252 10.236 9.252 12.598 13.000 13.000 6.750 K M12 M16 M20 M20 M22 M16 L 0.433 0.669 0.433 0.787 0.551 0.984 0.669 0.984 0.669 1.260 0.787 0.787 M 0.276 0.433 0.276 0.531 0.394 0.669 0.433 0.669 0.433 0.827 0.591 0.315 N 0.260 0.260 0.354 0.433 0.433 0.531 Fig. 1A 2 1B 2 1C 2 1C 2 1C 2 1D 2 I WILL LOAD ON YOUR TRUCK OR TRAILER FOR NO CHARGE. ANY CRATING THERE WILL BE EXTRA CHARGES. PLEASE EMAIL OR CALL 1-812-968-5230 IF YOU HAVE ANY QUESTIONS. FOR SHIPPING QUOTE PLEASE SEND A COMPLETE ADDRESS! IF ITEM IS BEING SHIPPED TO A BUSINESS OR RESIDENTIAL? WITH DOCK OR FORKLIFT? OR IF YOU WANT TO PICK UP AT FREIGHT TERMINAL. PLEASE CHECK OUT MY AUCTIONS. YOU BUY AS IS. I WILL COMBINE AUCTIONS TO SAVE ON SHIPPING. BUYER PAYS SHIPPING. PLEASE CHECK OUT MY OTHER AUCTIONS. Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Manufacturer	N/A
Model	CB21A11
Brand	N/A
MPN	A2-11
