Adafruit Si5351a Clock Generator Breakout Board 8khz To 160mhz Arduino 3.3v 5v

US $7.95

Carrollton, Texas, United States
Jun 9th

Open on mobile:

Atoms Industries Adafruit Si5351A Clock Generator Breakout Board - 8KHz to 160MHz Details: Frequency Range 8KHz to 160MHz Voltage3V - 5V Communcation protocol I2C Description Never hunt around for another crystal again, with the Si5351A clock generator breakout from Adafruit! This chip has a precision 25MHz crystal reference and internal PLL and dividers so it can generate just about any frequency, from <8KHz up to 150+ MHz. The Si5351A clock generator is an I2C controller clock generator. It uses the onboard precision clock to drive multiple PLL's and clock dividers using I2C instructions. By setting up the PLL and dividers you can create precise and arbitrary frequencies. There are three independent outputs, and each one can have a different frequency. Outputs are 3Vpp, either through a breadboard-friendly header or, for RF work, an optional SMA connector. We put this handy little chip onto it's own breakout board PCB, with a 3.3V LDO regulator so it can be powered from 3-5VDC. We also put level shifting circuitry on the I2C lines so you can use this chip safely with 3V or 5V logic. Best of all, Adafruit even has a great tutorial and library to get you started! Their code will help for use with the Arduino microcontroller and IDE but is easily ported to your favorite platform with I2C support Notes and Resources Some soldering is required Want to generate some frequencies quickly? Check out the tutorial in Adafruit Learning System Datasheet(s) Si5351A What's included 1x Adafruit Si5351A Clock Generator Breakout Board - 8KHz to 160MHz Male Headers You may also like... Atoms Industries carries lots of modules to help with your projects Check them out in the Atoms Industries Store FAQ Do you offer combined shipping? Combined shipping discounts are provided automatically through the Add To Cart feature. Most additional items added to the cart ship at a highly discounted rate. Be sure to check out the Atoms Industries Store, the more you buy the more you save! Payment Policy Paypal, credit card (Paypal account is not required), and any other option Paypal offers you are accepted. Order must ship to a confirmed address, otherwise payment will be refunded and order cancelled. Immediate payment is required. Shipping Policy You can not change your address after you have placed your order. Please check that your address is correct. Orders ship on the same or next business day. On most Saturdays too, but there is no guarantee on that. 99.9% of the time the day the label is created is the day the post office gets your package. Return Policy Returns are accepted only if the item has not been damaged or opened. The item must be returned in resalable condition within 14 days of delivery. Buyer pays return shipping. "Return to sender" packages will not be refunded shipping costs. Atoms Industries About us Since starting in 2012 Atoms Industries has come a long way. Even though it is very much a small business, it is my only business. I use every working moment I have to make this the company I have always wanted I worked for. The kind of company I would happily give my business. -Ben

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Adafruit Industries
MPN	2045
Model	Adafruit Si5351A Clock Generator Breakout Board
AtomsID	ASD1423
UPC	Does not apply
