Classic Iic I2c Logic Level Converter Bi-directional Module 5v To 3.3v Jbus

US $0.99

  • HK, China
  • Jun 9th
Description If you’ve ever tried to connect a 3.3V device to a 5V system, you know what a challenge it can be. bi-directional logic level converter is a small device that safely steps down 5V signals to 3.3V AND steps up 3.3V to 5V at the same time. This level converter also works with 2.8V and 1.8V devices. What really separates this Logic level converter from our previous versions is that you can successfully set your high and low voltages and step up and down between them safely on the same channel. Each level converter has the capability of converting 4 pins on the high side to 4 pins on the low side with two inputs and two outputs provided for each side. The level converter is very easy to use. The board needs to be powered from the two voltages sources (high voltage and low voltage) that your system is using. High voltage (5V for example) to the ‘HV’ pin, low voltage (3.3V for example) to ‘LV’, and ground from the system to the ‘GND’ pin. Dimensions: 0.63 x 0.52" (16.05 x 13.33mm) Package Included:   1 x New IIC I2C Logic Level Converter Bi-Directional Module 5V to 3.3V For Arduino Preview Engineered for professional eBay sellers! On Jan-05-15 at 18:24:41 PST, seller added the following information:
Condition:
New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...
Brand unbranded
MPN Does not apply
Size 16.05 x 13.33mm
UPC Does not apply
ISBN Does not apply
EAN Does not apply
