Anritsu ME7840/4 MS4623C/MN4783A Power Amplifier Test System VNMS 3D/4E/08/13/24, US $24,500.00 – Picture 0

Anritsu ME7840/4 MS4623C/MN4783A Power Amplifier Test System VNMS 3D/4E/08/13/24, US $24,500.00 – Picture 1

Anritsu ME7840/4 MS4623C/MN4783A Power Amplifier Test System VNMS 3D/4E/08/13/24, US $24,500.00 – Picture 2

Anritsu ME7840/4 MS4623C/MN4783A Power Amplifier Test System VNMS 3D/4E/08/13/24, US $24,500.00 – Picture 3

Anritsu Me7840/4 Ms4623c/mn4783a Power Amplifier Test System Vnms 3d/4e/08/13/24

US $24,500.00

Laguna Hills, California, United States
Apr 28th

Open on mobile:
QR code

Anritsu ME7840/4 (MS4623C with MN4783A) Power Amplifier Test System VNMS Configured with the following options: Options: 3D Source/3RD Port/Step ATTN 4E 6GHZ Noise Figure 08 Harmonic Measurements 13 Intermodulation Distortion 24 Processing Upgrade Description: Power Amplifier Test System VNMS with MS4623C Direct Receiver Access and MN4783A Handset Amplifier Test Set 6GHz With a single connection to the handset high power test set (ME7840/4), the Navigator™ software orchestrates the Scorpion® Direct Receiver Access (DRA) configuration to easily and accurately perform power amplifier measurements. The ME7840/4 test system consists of the MS4623C Direct Receiver Access Scorpion (DRA), the MN4783A Handset Amplifier Test Set and a library of external measurement software. Scorpion Navigator®orchestrates the calibration and performs measurements on power DRA Scorpion the Scorpion Direct Receiver Access version of the Vector Network Measurement System functions under control of the software residing in the PC through GPIB commands. The software supports tuning and alignment operations by generating real time graphic displays of the measured data on the PC screen. Under software control, 3rd, 5th and 7th order IMD products can be measured and displayed. Also, the Upper and Lower Side Band (USB and LSB) components of the IMD products are measured and displayed separately. The Anritsu ME7840/4 is intended for the measurement and real-time graphical display of the following parameters of a power amplifier in the frequency range of 10 MHz to 6 GHz: · S-parameters including Hot S22 and K-factor · Single-tone Power Sweep · Two-tone Power Sweep · Intermodulation Distortion · Harmonics · Noise Figure · Adjacent Channel Power Ratio (ACPR) The ME7840/4 test system is designed to facilitate alignment, tuning and pass/fail testing of the components, modules, and sub-assemblies of RF and microwave power amplifiers as well as the assembled amplifier systems. The DRA Scorpion includes the following capabilities: · Two internal, independent RF sources. · Each source has a range of –15 dBm to +10 dBm. A 0 dB to 70 dB step attenuator (10 dB / step) is provided for each source resulting in a power output range of –85 dBm to +10 dBm from each source · Complete built-in capability for IMD measurements. A combiner is provided in the test set. · Internal Transfer Switch enabling S22 and Hot S22 measurements. · The reflectometer set-up is provided in the test set. · Direct access to each of the four receiver channels (two reference channels and two test channels) for maximum flexibility in measuring forward and reverse S-parameters over a wide range of AUT output power. · The test set provides incident and reflected signal separation. MN4783A Frequency Range (MHz) 6GHz Maximum AUT Power Output 5W Reverse Measurements S22, Hot S22, S12 Tested, Guaranteed to be in working condition. CA residents add 8% CA State Sales Tax. Flexible rental terms available. Please contact sales@gstestequipment.com or call (949) 679-5561

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Anritsu
Model	ME7840/4 (MS4623C / MN4783A)
