Hp Hewlett Packard Agilent 8505a 500 Khz - 1.3 Ghz Rf Network Analyzer Option 05

US $99.99

Anaheim, California, United States
Apr 25th

Open on mobile:
QR code

What You'll get: HP Hewlett Packard Agilent 8505A 500 kHz - 1.3 GHz RF Network Analyzer Option 05 All Interconnect Cables Power Cord Not Included Other Accessories that are Not pictured or mentioned under "What You'll Get" are Not included Please visit our eBay Store for more similar items ! Testing: Unit does not power on and due to limited knowledge no further testing could be completed and therefore the unit is[[YouTube]] Sold AS-IS for parts or repair! Cosmetics: Pictures are of actual item. Please Reference Pictures for Cosmetics There are some noticable scuffs here and there and the unit was cleaned well. Taken from the Internet: SOURCE Frequency Characteristics Frequency Range 500 kHz to 1.3 GHz in three ranges; 500 kHz to 13 MHz, 500 kHz to 130 MHz and 500 kHz to 1.3 GHz Swept Frequency Accuracy ± 1% of range for linear sweep CW Frequency Accuracy ± 2 counts ± time-base accuracy Frequency Stability Better than ± 0.01% of reading ± 0.01% of frequency range over 10 minutes after warm-up. Frequency Counter Characteristics Frequency counter measurements are made at any one of five continuously variable marker positions without interrupting the swept RF signal. Resolution (least significant digit) Frequency Range (MHz) 0.5 to 1.3 0.5 to 130 0.5 to 1300 10 ms Sweep time 10 kHz 100 kHz 1 MHz 100 ms Sweep time 1 kHz 10 kHz 100 kHz > 1 second Sweep time 100Hz 1 kHz 10 kHz Counter Accuracy ± 2 counts ± time-base accuracy. Marker Frequency Accuracy ± 0.002% of scan width ± counter accuracy. Measured in CW ± DF Time-base Accuracy ± 5 ppm ± 1 ppm/°C ± 3 ppm/90 days Output Characteristics Output Power Range +10 dBm to -72 dBm. Attenuator Accuracy ± 1.5dBm over 70 dB range. Vernier Accuracy ± 1 dB. Leveling ± 0.5 dB from 500 kHz to 1.3 GHz Impedance 50O; ? 16 dB return loss at -10 dBm output level (<1.38 SWR). Residual FM Frequency Range (MHz) 0.5 to 13 0.5 to 130 0.5 to 1300 Residual FM 50 Hz rms 200 Hz rms 2 kHz rms Bandwidth 20 Hz-1 kHz 20 Hz-1 kHz 20 Hz-10 kHz Harmonics > 25 dB below main signal at +10 dBm output level. Sub-harmonics and Spurious Signals below -50 dBm at +10 dBm output level. General Characteristics Sweep Modes Linear Full, Log Full, Start/Stop 1, Start/Stop 2, Alternate, CW ± DF, and CW. Sweep Times 10 ms to 100 s in decade ranges. Trigger Modes auto, line sync., signal scan or external sync. RF Output Connector Type N female RECEIVER Frequency Range 500 kHz to 1.3 GHz Input Characteristics Input Channels three channels (R, A, and B) with 100 dB dynamic range. Damage Level +20 dBm or ? 50 V dc. Noise (10 kHz BW): -110 dBm from 10 to 1300 MHz; -100 dBm from 2 to 10 MHz; -95 dBm from 0.5 to 2 MHz. Impedance 50O: ? 20 dB return loss (<1.22 SWR). Typically > 26 dB return loss (<1.11 SWR). Magnitude Characteristics Absolute Frequency Response (A, B, R) ± 1.5 dB Ratio Frequency Response (A/R, B/R) ± 0.3 dB from 0.5 MHz Dynamic Accuracy ± 0.01 dB/dB from -20 to -40 dBm; ± 0.2 dB from -10 to -50 dBm; ± 0.5 dB from -50 to -70 dBm; ± 1.0 dB from -70 to -90 dBm; ± 2.0 dB from -90 to -100 dBm; ± 4.0 dB from -100 to -110 dBm. Reference Offset Range ± 199.9 dB Reference Offset Accuracy ± 0.03 dB ± 0.003 dB/dB of offset Marker Measurement Resolution 0.01 dB over any < 10 dB range; 0.1 dB over any ? 10 dB range. CRT Display Resolution 0.1 dB to 20 dB/division in 1, 2, 5 sequence. Phase Characteristics Frequency Response ±3° from 500 kHz to 750 MHz; ±5° from 750 MHz to 1.3 GHz. Range ±180° Accuracy ±0.01°/degree for ±170°; ±0.01°/degree ±0.5° for ±180° Dynamic Accuracy (in 10 kHz Bandwidth) ±0.02° /dB from -20 to -40 dBm; ±0.5° from -10 to -50 dBm; ±1° from -50 to -70 dBm; 3° from -70 to -90 dBm. Crosstalk see amplitude crosstalk specification. Reference Offset Accuracy ±0.3° ±0.5° of offset. Marker Measurement Resolution ±0.1° over < 100° range and 1° for ? 100° range. CRT Display Resolution 1° to 180° per division in 8 steps. Polar Characteristics Frequency Response, Dynamic Response, Reference Offset and Marker Measurement specifications are the same as magnitude and phase characteristics. CRT Display Accuracy Actual value is within less than 3 mm circle of the displayed value. Tracking Between dB Offset Controls and Polar Full Switch Positions =0.2 dB Full Scale Magnitude Range 1 to 0.01 in a 1, 0.5, 0.2 sequence. Delay Characteristics Frequency Response ± 1 ns from 500 kHz to 1.3 GHz. Delay Accuracy1 ± 3% of reading ± 3 units (Units = 1 ns for 0.5 to 1300 MHz range, 10 ns for 0.5 to 130 MHz range, and 100 ns for 0.5 to 13 MHz range.). 1 ±3 units may be calibrated out with thru connection. Range Resolution and Aperture Frequency Range (MHz) 0.5 to 13 0.5 to 130 0.5 to 1300 Range 0 to 80 µs 0 to 8 µs 0 to 800 ns Resolution: CRT Marker Marker with Delay scale/Div Switch set to 100 ns 100 ns 10 ns (< 1 µs) 10 ns 10 ns 1 ns (=100 ns) 1 ns 1 ns 0.1 ns (=10 ns) Aperture 7 kHz 20 kHz 200 kHz Reference Offset Range ± 1999 dB Reference Offset Accuracy ± 0.3 units ± 0.3% of offset Electrical Length/ref. plane extension characteristics Calibrated Electrical Length Range and Resolution2 Frequency Range (MHz) 0.5 to 13 0.5 to 130 0.5 to 1300 Range X1 X10 ± 19.9 m ± 1.99 m ± 19.9 cm ± 100 m ± 10 m ± 1 m Resolution X1 10 cm 1 cm 0.1 cm X10 1 m 10 cm 1 cm Calibrated Electrical Length Accuracy ± 3% of reading ± 1% of range Linear Phase Substitution (degrees/scan) Range ± 1700° per scan with 0° offset ± 1.4 km/scan width (MHz) or ± 4.7 µs/scan width (MHz) Linear Phase Substitution Resolution 10° Linear Phase Substitution Accuracy ± 3% of reading ± 10° / scan Phase Compensation Linearity < 0.2% of phase slope inserted GENERAL CHARACTERISTICS RF Input Connectors type N Female Display Bandwidth selectable IF bandwidths of 10 kHz and 1 kHz. A video filter position is also provided. CRT Overlays Smith Charts (2, 1, 0.5, 0.2, 0.1 full scale), Log Charts (10 MHz, 100 MHz and 1000 MHz) CRT Photography HP 197A Opt 006 camera or HP 197A with 10375A Bezel Adapter required to fit 8505A display. A CRT illumination control is provided. Auxiliary Outputs Channel 1 and 2 Outputs 0.25 V/display division Sweep Output 0.25 V/display division Pen Lift DC coupled, 200 mA current sink. Programming The 8505A has a remote programming interface using the Hewlett-Packard Interface Bus with Learn Mode. Included are one 2 m (HP 10631B) and one 0.5 m (HP 10631D) HP-IB cables. Power selection of 100, 120, 200 or 240 V +5% -10%. 50 to 60 Hz approximately 275 watts. Policies & Definitions: Shipping Most items ship out within 1-2 BUSINESS days after the payment clears. We allow local pick up. Handling fee of $9.99 and CA tax will apply. We combine shipping to save you money if the items can be combined and shipped safely. We offer a combined shipping discount of $3 for each additional item purchased. Free shipping offers do NOT apply to Puerto Rico, Alaska, Hawaii and international transactions Definitions: GUARANTEED WORKING MEANS : The item is guaranteed working as long as we receive it back within 30 days from the purchase date. We will replace the item at no additional cost if the item is DOA. If replacement is Not available, we will refund the purchase price. Please bid accordingly AS-IS MEANS: The item is sold AS-IS Where is. This means that the buyer acknowledges that the item may or may Not be working and that the item may or may Not be complete and the buyer is willing to accept the risk. Please bid accordingly Shipping and handling cost is Not refundable under any circumstances and the buyer is responsible for any additional shipping cost. please bid accordingly. Return Policy Every item we sell is carefully inspected before it is shipped and is tested to the best of our ability. If merchandise is Not as described please keep all packing materials, brochures, paperwork, etc. and contact us immediately after your package arrives for a return authorization claim number or to file a claim with the carrier on your behalf. * All claims MUST be made within 3 days of receipt of order *Shipping charges will not be refunded * Non-defective returned items are subject to a 30% restocking fee. Ebay's Required Disclosure for Medical Equipment: "The sale of Some medical equipment may be subject to regulation by the U.S. Food and Drug Administration and state and local regulatory agencies. If the item is subject to FDA regulation, I might verify your status as an authorized purchaser of this item before shipping of the item." The shipping weight for this item is approximately 51 LB -14498 -14498 - c12 Powered by SixBit's eCommerce Solution

Condition:	For parts or not working: An item that does not function as intended and is not fully operational. This includes items that are defective in ways that render them difficult to use, items that require service or repair, or items missing essential components. See the seller’s listing for full details. ...	Brand	HP
Model	8505A
