Bk Precision 2709b Tool Kit Auto Ranging True Rms Digital Multimeter

US $105.00

Melrose, Massachusetts, United States
Apr 23rd

Open on mobile:
QR code

BK Precision 2709B Tool Kit Auto Ranging True RMS Digital Multimeter New - Factory Authorized Distributor - Factory Warranty BK Precision 2709B Shown The 2709B is a full featured auto ranging true RMS DMM that combines performance, value and functionality The 6600 count LCD has a green back light that allows the meter to be used in dimly lit environments The 2709B can measure resistance values up to 66 Mohm and capacitance to 66 uF With the auto power off feature you wonA’t have to worry about accidental battery consumption Value-packed features make this meter a must in every "Tool KitA®" Features a Magnetic hanger, One-handed operation, True RMS, Auto/manual ranging, Diode test, and Continuity test DC voltage to 1000 V Measures up to 10 A (AC & DC) AC voltage to 750 V Resistance to 66 Mohm Capacitance to 66 uF Frequency counter to 66 MHz Specifications DC Volts Ranges 660 mV, 6.6 V, 66 V, 660 V, 1000 V Resolution 0.1 mV, 1 mV, 10 mV, 100 mV, 1 V Accuracy A±(0.5 % rdg + 2 dgts) Overload Protection 1000 VDC or 750 VACrms Input Impedance 660 mV: >100 M?; 6.6 V: 10 M?; 66 V to 1000 V: 9.1 M? AC Volts True RMS Applies; 50 Hz - 500 Hz Ranges 660 mv, 6.6 V, 66 V, 660 V, 750 V Basic Accuracy 660 mV range at 50 Hz to 60 Hz A±(1.5 % rdg + 8 dgts) 6.6 V to 660 V ranges: A±(1.5 % rdg + 8 dgts) 750 V range: A±(2.0 % rdg + 8 dgts) Resolution 0.1 mV, 1 mV, 10 mV, 100 mV, 1 V Crest Factor <3 Input Impedance 660 mV: >100 M?; 6.6 V: 10 M?; 66 V to 750 V: 9.1 M? Overload Protection 1000 VDC or 750 VACrms DC Current Ranges 660 uA, 6600 uA, 66 mA, 400 mA, 10 A Resolution 0.1 uA, 1 uA, 10 uA, 100 uA, 10 mA Accuracy 660 uA to 400 mA ranges: A±(1.5 % rdg + 2 dgts) 10 A range: A±(3.0 % rdg + 3 dgts) Input Protection 0.5 A/500 V & 10 A/600 V fast blow ceramic fuses 10A Input 10 A for 60 sec max. followed by a 10 minute cooling period AC Current True RMS Applies; 50 Hz - 500 Hz Ranges 660 uA, 6600 uA, 66 mA, 400 mA, 10 A Resolution 0.1 uA, 1 uA, 10 uA, 100 uA, 10 mA Accuracy 660 uA to 400 mA ranges: A±(2.0 % rdg + 10 dgts) 10 A range: A±(3.5 % rdg + 10 dgts) Crest Factor <3 Input Protection 0.5 A/500 V & 10 A/600 V fast blow ceramic fuses 10A Input 10 A for 60 sec max. followed by a 10 minute cooling period Resistance Ranges 660 ?, 6.6 k?, 660 k?, 6.6 M?, 66 M? Resolution 0.1 ?, 1.0 ?, 10 ?, 1 k?, 10 k? Accuracy 660 ?to 660 k?ranges: A±(1.2 % rdg + 5 dgts) 6.6 M?range: A±(2.0 % rdg + 5 dgts) 66 M?range: A±(3.5 % rdg + 5 dgts) Open Circuit Voltage (typical) -0.45 VDC (-1.2 VDC on 660 ?range) Overload Protection 500 VDC/ACrms Capacitance Ranges 6.6 nF , 66 nF, 660 nF, 6.6 uF, 66 uF, 660 uF, 6.6 mF, 66 mF Resolution 1 pF, 10 pF, 100 pF, 1 nF, 10 nF, 100 nF, 1 uF, 10 uF Accuracy 6.6 nF range: A±(3.0 % rdg + 30 dgts) 66 nF to 660 uF ranges: A±(3.0 % rdg + 5 dgts) 6.6 mF to 66 mF ranges: A±(5.0 % rdg + 20 dgts) Overload Protection 500 VDC/ACrms Frequency Ranges 660 Hz, 6.6 kHz, 66 kHz, 660 kHz, 6.6 MHz, 66 MHz Resolution 0.1 Hz, 1 Hz, 10 Hz, 100 Hz, 1 kHz, 10 kHz Accuracy A±(0.1 % rdg + 3 dgts) Sensitivity 10 Hz to 6.6 MHz: >2.5 Vrms, 6.6 MHz to 66 MHz: >2.5 Vrms <5 Vrms Minimum Pulse Width >25 ns Duty Cycle Limits >30 % and <70 % Overload Protection 500 VDC/AC rms Diode Test Test Current 1.2 mA (typical) Resolution 1 mV Accuracy A±(3.0 % rdg + 3 dgts) Audible Indication <0.03 V Open Circuit Voltage 3.5 VDC (typical) Overload Protection 500 VDC/ACrms Continuity Tone Audible Indication Less than 30 ? Response Time 100 ms Overload Protection 500 VDC/ACrms General Characteristics Display 3 3/4 digit, 6600 count LCD Polarity Automatic, positive implied, negative polarity indication Overrange OL or -OL is displayed Low Battery Indication The battery symbol will display when battery voltage drops below operating levels Measurement Rate 2 times per second Auto Power Off Approximately 30 minutes Operating Environment t0A?C to 50A?C at <70 % relative humidity Storage Environment -20A?C to 60A?C at 0 to 80 % relative humidity Accuracies Stated accuracy at 23A?C +5A?C at <75 % relative humidity Temperature Coefficient 0.1 x (specified accuracy) per A?C. (A?C to 18A?C, 28A?C to 50A?C) Power Single standard 9 volt battery, NEDA 1604, JIS 006P, IEC 6F22 Battery Life 150 hours typical Dimensions 165 mm (H) x 78 mm (W) x 42.5 mm (D) Weight Approximately 10.3 oz. (377 g) with battery and hanger Included Accessories 1 - Test Leads 1 - 9 Volt Battery 1 - Instruction Manual 1 - Spare Fuse Included Click here for complete specifications FREE Fed-Ex Ground Shipping on items OVER $75 to continental U.S. PO Boxes/APOs require USPS shipping, may experience longer lead times. 6.25% Sales Tax for shipping to Massachusetts (Add an additional $24 for shipments to AK, HI, or PR.) Terms and Conditions Have a Question? Send us a message (Contact Seller). We are shipping from just north of Boston, MA in the United States. For international customers, do not assume a product will work in your country due to various International Voltage requirements. Ask first if you are not sure. Warranty: We are an authorized distributor. Item includes full manufacturerA’s warranty. International Shipping Terms: * International customers are responsible for all shipping charges, including any duties or taxes that may be enforced by their respective country. * USPS is the most economical shipping method for international customers. With this often comes a slightly delayed lead-time or erratic tracking information. We ask for your patience, and we will do the best we can to see you get your shipment quickly and accurately. Feedback: We appreciate your Positive feedback. We leave feedback for buyers as soon as our transactions complete. If you have any problems with the sale, we will do anything within reason to correct or improve your experience. If negative feedback is left prior to an attempted resolution, we reserve the right to accept that as the final resolution. We will not accept a return or issue a refund. *Note Estimated Delivery time above. Please contact us if you require specific details, or have a required delivery date. Please contact us for shipping rates to any overseas US territories including: Northern Mariana Islands, Guam, Puerto Rico, Palau, U.S. Virgin Islands and American Samoa.

Condition:

New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...

UPC

817050270921
