Ble4.0 Bluetooth 2.4ghz Wireless Module Based On Nrf51822 Board Core51822

US $68

shenzhen, guangdong, China
Jun 9th

Open on mobile:
QR code

Core51822 Overview Core51822 is a wireless module based on nRF51822 - the Multiprotocol Bluetooth® 4.0 low energy/2.4 GHz RF SoC designed for ULP (ultra low power) wirelesss applications. Core51822 Specifications Onboard chip: nRF51822 Communication distance (open outdoor@1M data rate): 30m Frequency range: 2.4GHz Operating voltage: 2.0V ~ 3.6V Operating temperature: -40°C ~ 85°C Dimension (PCB): 24.5mm x 32.26mm Expansion pinheader: all the I/Os except P0.26 and P0.27 Pinheader pitch: 2.00mm Spacing between pinheaders on the left side and the right side: 18.00mm Antenna: onboard antenna nRF51822 Features 2.4 GHz multiprotocol RF transceiver ARM® Cortex™-M0 32 bit processor 128 bit AES HW encryption 256kB flash & 32kB RAM Programmable Peripheral Interconnect (PPI) Digital interfaces: SPI, I2C, UART 10 bit ADC Programmable output power: -20 to +4 dBm Independent application development and protocol stack Fully compatible with NRF24L series Pinout compatible with NRF51xxx series Global separate power management Operating voltage: 1.8 V ~ 3.6 V Applications Wearable devices Bluetooth intelligent application Mobile phone accessories RFID labels Smart home appliances Industry control Data acquisition system Revision History 2015.06, Core51822 upgrades the onboard chip to Rev3, features 32kB RAM, supports higher version SDK, and all the demo codes are still compatible with the Rev2 ones. Package Contents Core51822 x 1 Terms & Conditions Payment: ∴ We accept ONLY PAYPAL payment. ∴ A non-payment dispute will be open if a full payment is not received after 14 days of auction. Shipping: ∴ We ship items to Worldwide! ∴ Please confirm your address in paypal is right, phone number is better included as a vital clue for shipping. ∴ All items will be shipped within 2 working-days on receipt of cleared payment. ∴ We Ship via normal registered Air-Mail with tracking number, please see the details of " Shipping and Payments", for the price is very low, When you pay extra added price will be sent by a faster express way. ∴ Due to the complexity of international shipping, we can't provide any estimate and quote, buyers are responsible for import customs duty. We will send as gift or declare low value to avoid customs duty if you will(note via ebay message when you make an order). ∴ we also provide Express DHL/UPS/EMS/FedEx besides normal registered AirMail, If you want to get the items faster and accept the extra charges for the shipping, please email us before payment. ∴ More details Return Policy: ∴ We have deeply checked and tested item quality before shipment. ∴ We are happy to make an exchange or refund the item total value once the item is confirmed as defective or wrong result from our mistake. ∴ Return items should include original packaging and all accessories. ∴ We will pay for the shipping cost of resending items to you, while buyers are responsible for the postal cost of returning the items. Working Days: ∴ Customer support is available from 9:00 a.m. to 6:00 p.m. (GMT+8), Monday to Saturday. ∴ Our office is closed on Sunday and public holidays. Message will sometimes be delayed to reply. Pls forgive this. Feedback: ∴ If you're satisfied with our item and service, please leave POSITIVE FEEDBACK, it's fatal to us. ∴ Your recognition will make us more confident to develop business and serve you better. ∴ Once you have any problems, please feel free to contact us first. We'll strive for the best to help you!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Model	Core51822
Brand	XYGSHARE
Features	Onboard chip: nRF51822
MPN	Core51822
UPC	711707257443
