High Voltage Dc-dc Boost Converter 45v-390v 110v/220v Zvs Capacitor Charging Etc

US $10.49

GuangZhou, China
Jun 9th

Open on mobile:
QR code

High Voltage DC-DC Boost Converter 8V-32V to 45V-390V For ZVS Capacitor Charging etc Description Module specifications: Module Name: High Voltage boost converter module Module Properties: non-isolated step-up module Input voltage: two input voltage range selectable, (jumper selectable through the back of the PCB, default setting 10-32V input) 1, 8V-16V input 2, 10V-32V input Input Current: 5A (MAX) Quiescent current: 15mA (12V step up to 50V, the higher the output voltage will increase the quiescent current) Output voltage: ± 45-390V continuously adjustable (the default output ± 50V. This module has regulator function, after adjusted output voltage is stable and unchanging, not with changes in input voltage changes) Output Current: 0.2A MAX (affected by input voltage and dropout voltage,the higher the output voltage, the smaller the output current) Output Power: 40W (peak 70W) Working temperature: -40℃ ~ + 85℃(if temperature too high , please enhance heat dissipation) Operating frequency: 75KHz Conversion efficiency: up to 88% (affected by input voltage, output volage, current and dropout voltage ) Short circuit protection: Yes. (Input 10A fuse, at the output please do not short circuit arc, it may damage the electronic component, if you need please add power resistor in series for limiting) Overcurrent protection: Yes. (Input current exceeds 4.5A, reducing the output voltage) Overvoltage protection: Yes (Output voltage exceeds 410V, lowering the output voltage) Input reverse polarity protection: Yes (non-self-healing, reverse burning fuse, you have better not reverse it.) Installation: four 3mm screws Connection: solderless terminals output Module dimensions: 60(L)*50(W)*22(H)mm The capacitor charging time measured data: 470uF full charge to 390V time is 2 seconds 1000uF full charge to 390V time is 4 seconds 2200uF full charge to 390V time is 8 seconds 4700uF full charge to 390V time is 18 seconds Warning! The module output is high voltage, on people, animals have life-threatening, the course please pay attention to safety precautions. We are not responsible. Applications: the capacitor charging, guns power. the power supply for your electronic device, can set the output voltage value according to your system. voltage pressure test power, glow tube power. hunting, rodent. Package includes: 1 x DC Boost Converter ±45-390V output adjustable Payment We only accept PayPal. Payment must be made within 7 calendar days of the auction end time. We reserve the right to cancel your order if the payment is not made within 7 calendar days of checkout. We will use your Ebay/Paypal shipping address as the delivery address. Please make sure to provide us with correct and detailed shipping address. To Russia, please the receiver name must write your full name as post office required. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Shipping Detail All the items to USA will ship via ePacket with tracking number. To UK and Australia the buyer can choose "Expedited Int'l Shipping", we also will ship via ePacket with tracking number, it is better than registered mail,usually delivery time is 7-20 business day. But to Australia ZIP code 2898/2899/6798/6799/7151 can NOT ship via ePacket. Other countries, total price below $30 we will ship your item without tracking number. Otherwise, if you need Registered Mail shipping, please add $2.5(Can choose "Standard Int'l Shipping",we will ship via registered mail). Usually all the items will be shipped via Hong Kong Post Airmail or China Post Airmail. If you need the other express way(EMS/DHL/FedEx/UPS),please contact with us for the correct price. Your order will be dispatched within 2 business days after the full payment is cleared. Airmail Packets' Delivery Time(reference only): USA,Australia,New Zealand,Southeast Asia, East Asia. 7-20 business days. Most European countries (France,Spain,Germany,UK,Sweden, Norway, Denmark,Netherlands,Austria,Portugal, Croatia, Finland, Switzerland, etc.) ,Canada,10-25 business days. Some remote city will take more than 25 business day. Italy,Russia, Brazil, Turkey, Ukraine, India, 14-35 business days, 90% take long time. Eastern Europe,West Asia,Central Asia, 15-30 business days,80% take long time. Africa,Chile,Argentina,Mexico,Other Countries. 15-40 business days,usually long time. Delivery time depends on postal process and other factors(Weather,Vacation,Customs,etc.),it can receive as fast as 7 days,but it can take as long as 4-7 weeks in some cases. If you do not get your item in reference delivery time, please contact us first through ebay message (Please do NOT open any case), we will reply you as soon as possible(within 24 business hours). Return Policy Please contact us before you leave Negative or Neutral Feedback if you are not satisfied with our products,we will resolve it asap. DOA(Dead On Arrival) or Wrong Item will be offered exchange. Refund will be offered if stock is not available Defective goods must be returned within 30 days after receiving it for exchange or refund. Buyer is responsible for return shipping cost in any situations. Contact us Please feel free to contact us from ebay if you have any questions , we will reply you within 48 hours except the weekends and public holidays. Please contact with us before you leaving Negative or Neutral feedback, and please DO NOT open any case, we will try my best to resolve your problems ASAP. Engineered for professional eBay sellers!

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country of Manufacture	China
Output current	0.2A(MAX)
Input voltage	8V-32V
Model	Voltage step up converter
Output voltage	±45V-390V
UPC	Does not apply
