Conair Vacuum Loader Matching Stainless Steel Hopper Rdn Novatec Aec Whitlock

US $6900

Fort Worth, Texas, United States
Jun 7th

Open on mobile:

This was purchased new from Con-Air in 2010 specifically for conveying dried acrylic from the druer hopper to the extruder. This loader and hopper never had colored or re-grind material in it. Still in excellent shape and hopper is in excellent shape as well. There is a link about all the option of the ConAir AL-5 Specifications about Con-Air Al-5 Vaccuum Loader Will ship strapped to a pallet LTL, message for a quote. 0.5 {14.0} Loader body diameter inches {mm} 8.0 {203.0} 12.0 {304.0} Material/vacuum line inches {mm} 1.5 - 2.0 {38 - 51} 1.5 - 2.0 {38 - 51} Loader maximum temperature rating °F(°C) 180 {82} 180 {82} 150 {66} Vacuum motor 5/8 hp - 2 brush 7/8 hp - 4 brush 1.3 hp - brushless Nominal throughput lbs/hr {kg/hr} 200.0 {90.0} 500.0 {227.0} 1000.0 {454.0} Maximum conveying distance ft {m} 50 {15.2} 75 {22.9} 120 {36.6} Loader diameter inches {mm} 8.0 {203.0} 12.0 {304.0} Discharge type Gravity flapper or Positive discharge Demand sensor Integrated reed switch/ Remote capacitance sensor (optional) Dimensions inches {mm} A - Height above mounting plate 20.4 {518.2} 23.2 {588.52} B - Height above mounting plate with open lid 29.7 {754.4} 34.0 {863.6} C - Depth below mounting plate 4.9 {124.5} 8.1 {206.3} with positive discharge 10 {254} 16 {406} D - Height to center of material inlet 8.8 {223.5} 8.6 {219.5} Weight lb {kg} Installed 28 {13} 49 {22} Shipping 50 {23} 65 {30} Compressed air requiements Psi recommended 80 80 Available voltages 110/220 VAC 110/220 VAC Direct Feed Model (Glass Hopper) Model AL2 Viewing chamber model 3 lb 11 lb 21 lb Viewing chamber capacity lb {kg} 3.0 {1.4} 11.0 {4.9} 21.0 {9.5} Isolator valve standard standard standard Dimensions inches {mm} E - Height above mounting plate 32.4 {822.5} 38.1 {966.7} 49.6 {1260.6} F - Height to center of material inlet 20.8 {527.1} 26.5 {672.6} 38.0 {965.2} Weight lb {kg} Installed 43 {19} 49 {22} 59 {27} Shipping 65 {30} 71 {32} 82 {37} Direct Feed Model (Stainless Steel Hopper) JIT Model AL2 AL5 Viewing bin model 10 lb 20 lb 40 lb Viewing bin capacity lb {kg} 11.1 {5.1} 24.3 {11.0} 41.5 {18.8} Isolator valve standard standard standard Dimensions inches {mm} G - Height above mounting plate 34.3 {871.2} 42.1 {1069.3} 45.2 {1148.1} H - Height to center of material inlet 22.6 {574.0} 27.7 {703.6} 30.8 {782.3} Weight lb {kg} Installed 45 {20} 80 {36} 85 {39} Shipping 67 {30} 96 {44} 101 {46}
