Direct Current (dc) Arc Flash Hazard Analysis And Labeling Software

US $700

Etobicoke, Ontario, Canada
Oct 21st

Open on mobile:
QR code

Direct Current (DC) Arc Flash Analytic version 3.0 (DCAFA V3.0) software Free Demo ! Try before you buy ! DC Arc Flash Analysis and Label Making Software ! A must have for electrical inspectors and contructors, consulting, specifying, safety and plant engineers, maintenance supervisors, safety managers ! Ensure compliance with NEC, OSHA, NFPA 70E, IEEE P1584 and CSA Z462 standards and regulations! TRY BEFORE YOU BUY, Click Here to Download Demo ! Demo Note: To install, just run the download file and follow instructions. DC-Arc-Flash-Analytic version 3.0 (DCAFA V3.0) software for Windows operated PCs has been developed as an easy to use and comprehensive tool for calculating arc incident energy and arc flash boundary. This software simplifies determining incident energy at working distance, arc flash, limited and restricted approach boundaries in DC power systems when work is to be performed on or near the energized equipment. The program performs the analysis by taking into account power system voltage, available short circuit current, circuit time constant, equipment configuration, working distance and protective device time-current characteristics. DCAFA V3.0 will also assist you in selection of proper Personal Protective Equipment (PPE) and creation of arc flash & shock hazard warning labels. The program is applicable for systems with voltages from 50 to 30,000V DC, short circuit fault currents from 100A to 20kA, circuit time constants from 0 to 50msec, conductor gaps from 1 mm. up to the lesser of 300 mm. and the maximum value where the arc can likely be sustained under the specified system voltage, available short circuit current and circuit time constant. Features and Benefits: Calculator-style interface makes complex calculations easy to understand; Provide a safer working environment by specifying the proper level of personal protective equipment. Wearing inadequate clothing is dangerous for obvious reasons, but wearing too much clothing is dangerous due to limited mobility and visibility; Design safer power systems while insuring compliance with NEC 110.16, OSHA, NFPA 70E and CSA Z462 standards and regulations; Evaluate threshold incident energy for a second degree burn; Avoid potential fines, lost productivity, and increased insurance and litigation costs; Add fuse and circuit breaker data including time-current characteristics for the devices that are not already featured in the built-in protection device library. Save time by generating arc flash warning labels in electronic high resolution JPG, BMP, TIF, GIF and PDF formats; Save reports including equipment data, calculation results, warning label. Create, print, save warning labels; Save equipment data, calculation results for future reference or printing; TRY BEFORE YOU BUY, Click Here to Download Free Demo ! DC Arc Flash Analytic v3.0 is available by mail in disk format or via download from our web server. When you purchase your copy of DCAFA V3.0, we need you to provide the end-user's full name and company name. This information is used to generate end user program registration key.
