Dt-9917 Professional Digital Multimeters Dmm

US $360

hk, Hong Kong
May 29th

Open on mobile:
QR code

Multimeters DT-9917 Professional Digital Multimeters DMM MIB-INSTRUMENTS "Can Buy It Now in my ebay store" DT-9917 Professional Digital Multimeter's basic info DT-9917 is a new series 4000 counts multimeter. It sets the standard with a combination of precision, features, easy to use, safety and reliability. Description of DT-9917 Professional Digital Multimeter Features: 1. 4000 counts LCD display with function indication; 2. Auto power off and Low battery indication; 3. Relative zero mode; 4. Data hold function. DC Voltage (Auto-ranging): Range: 400.0mV, 4.000V, 40.00V, 400.0V, 1000V Basic Accuracy: +0.5% Resolution: 0.1mV AC Voltage (Auto-ranging except 400mV): Range: 400.0mV, 4.000V, 40.00V, 400.0V, 1000V Basic Accuracy: +0.8% Resolution: 0.1mV DC Current (Auto-ranging for uA and mA): Range: 400.0uA, 4000uA, 40.00mA, 400.0mA, 10A Basic Accuracy: +1.8% Resolution: 0.1uA AC Current (Auto-ranging for uA and mA): Range: 400.0uA, 4000uA, 40.00mA, 400.0mA, 10A Basic Accuracy: +1.2% Resolution: 0.1uA Resistance (Auto-ranging): Range: 400.0W, 4.000kW, 40.00kW, 400.0kW, 4.000MW, 40.00MW Basic Accuracy: +0.8% Resolution: 0.1W Capacitance (Auto-ranging): Range: 4.000nF, 40.00nF, 400.0nF, 4.000uF, 40.00uF, 200.0uF Basic Accuracy: +3.0% Resolution: 1pF Frequency (Auto-ranging): Range: 9.999Hz, 99.99Hz, 999.9Hz, 9.999kHz, 99.99kHz, 999.9kHz, 9.999MHz Basic Accuracy: +1.5% Resolution: 0.001Hz Duty Cycle: Range: 0.1%~99.9% Basic Accuracy: +1.2% Resolution: 0.1% Temperature Measurement: MAX: 760C/1400F Basic accuracy: +3.0% Resolution: 1C/1F Diode Test and Audible continuity: Diode Test: Test current of 0.3mA typical, open circuit voltage 1.5V DC typical Audible continuity: Audible threshold: Less than150W, Test current: <0.3mA Specifications: Function Range Resolution Accuracy DC Voltage 400.0mV 0.1mV +0.5% of rdg + 2 dgts 4.000V 1mV +1.2% of rdg + 2 dgts 40.00V 10mV 400.0V 100mV 1000V 1V +1.5% of rdg + 2 dgts AC Voltage 400.0mV 0.1mV +1.5%of rdg + 70 dgts 4.000V 1mV +1.2% of rdg + 3 dgts 40.00V 10mV +1.5% of rdg + 3 dgts 400.0V 100mV 1000V 1V +2.0% of rdg + 4 dgts DC Current 400.0uA 0.1uA +1.0% of rdg + 3 dgts 4000uA 1uA +1.5% of rdg + 3 dgts 40.00mA 10uA 400.0mA 100uA 10A 10mA +2.5% of rdg + 5 dgts AC Current 400.0uA 0.1uA +1.5% of rdg + 5 dgts 4000uA 1uA +1.8% of rdg + 5 dgts 40.00mA 10uA 400.0mA 100uA 10A 10mA +3.0% of rdg + 7 dgts Resistance 400.0W 0.1W +1.2% of rdg + 4 dgts 4.000kW 1W +1.0% of rdg + 2 dgts 40.00kW 10W +1.2% of rdg + 2 dgts 400.0kW 100W 4.000MW 1kW 40.00MW 10kW +2.0% of rdg + 3 dgts Capacitance 4.000nF 1pF +5.0% of rdg+20 dgts 40.00nF 10pF +5.0% of rdg + 7 dgts 400.0nF 0.1nF +3.0% of rdg + 5 dgts 4.000uF 1nF 40.00uF 10nF 200.0uF 0.1uF +5.0% of rdg + 5 dgts Frequency 9.999Hz 0.001Hz +1.5% of rdg + 5 dgts 99.99Hz 0.01Hz 999.9Hz 0.1Hz +1.2% of rdg + 3 dgts 9.999kHz 1Hz 99.99kHz 10Hz 999.9kHz 100Hz 9.999MHz 1kHz +1.5% of rdg + 4 dgts Temperature -20C~+760C 1C +3% of rdg +5C/9F -4 F~+1400F 1F Duty Cycle 0.1%~99.9% 0.1% +1.2% of rdg + 2 dgts Accuracy is given at 18 C to 28 C (65 F to 83 F), less than 70 % RH The instrument complies with: EN61010-1. Insulation: Class2, Double insulation. Overvoltage category: CATIII 1000V, CATIV600V. Polarity: Automatic, (-) negative polarity indication. Overrange: OL mark indication. Measurement rate: 2 times per second, nominal. Operating environment: 0 C to 50 C (32 F to 122 F) at < 70 % relative humidity. Storage temperature: -20 C to 60 C (-4 F to 140 F) at < 80 % relative humidity. Power: One 9V battery , NEDA 1604, IEC 6F22. Dimensions: 182 (H) x 82 (W) x55 (D) mm Weight: Approx.: 375g. Payment Shipping We accept Paypal, credit card through Paypal. Buyer may need to pay for import tax depend on your country's custom. You can ask us for more detail. We ship to international and item will be shipped by airmail from HongKong. Items are shipped within 2-3 business day after receive cleared payment. An additional USD2 for insurance Most item will arrive within 8-14 business days. It depend on your location. In some case, ship to some countries will take over 3 weeks, especially brazil, Italy and France . Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items. On Aug-12-14 at 02:33:51 PDT, seller added the following information: Powered by eBay Turbo Lister The free listing tool. List your items fast and easy and manage your active items.
