Dual Dc Stepper Motor Drive Controller Board Module Tb6612fng Replace L298n H2

US $2.69

HK, Hong Kong
Jun 9th

Open on mobile:
QR code

Pictures Specifications Features: The TB6612FNG motor driver can control up to two DC motors at a constant current of 1.2A (3.2A peak). Two input signals (IN1 and IN2) can be used to control the motor in one of four function modes - CW, CCW, short-brake, and stop. The two motor outputs (A and B) can be separately controlled, the speed of each motor is controlled via a PWM input signal with a frequency up to 100kHz. The STBY pin should be pulled high to take the motor out of standby mode.CJMCU. Logic supply voltage (VCC) can be in the range of 2.7-5.5VDC, while the motor supply (VM) is limited to a maximum voltage of 15VDC. The output current is rated up to 1.2A per channel (or up to 3.2A for a short, single pulse). Board comes with all components installed as shown. Decoupling capacitors are included on both supply lines. All pins of the TB6612FNG are broken out to two 0.1" pitch headers; the pins are arranged such that input pins are on one side and output pins are on the other. Standby control to save power CW/CCW/short brake/stop motor control modes Built-in thermal shutdown circuit and low voltage detecting circuit All pins of the TB6612FNG broken out to 0.1" spaced pins Filtering capacitors on both supply lines Specifications: Power supply voltage: VM=15V max, VCC=2.7-5.5V Output current: Iout=1.2A(average) / 3.2A (peak) Net Weight: 5 g Dimensions: 20mm x 20mm Color: red Package Included: 1* The TB6612FNG motor driver module Note: A. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. B. Please check with your country's customs office to determine what these additional costs will be prior to bidding/buying. Shipping Options We offer WORLDWIDE SHIPPING. (Except China, Italy, and Croatia) Orders will be processed and dispatched within 24-48 hours after payment is clear. We only ship to confirmed?eBay addresses. Your?eBay?address MUST MATCH your Shipping address. If you have not received your shipment within 30 business days from payment, please contact us. We will track the shipment and get back to you as soon as possible. Our goal is customer satisfaction! Please note that estimated delivery time is depended on destination countries, and may subject to customs clearance process, and weather condition in your area. Country Delivery Time (days) Not including Handling time, weekend, and holidays 9-12 13-18 19-24 25-29 30-35 >35 United States 5% 50% 30% 11% 5% Refund United Kingdom 10% 63% 19% 3% 4% Refund Australia 21% 50% 14% 7% 7% Refund France 11% 29% 44% 10% 7% Refund Germany 11% 22% 30% 21% 16% Refund Canada 0% 47% 31% 18% 4% Refund Spain 4% 25% 48% 13% 11% Refund Notice On Sep-15-15 at 04:36:43 PDT, seller added the following information:

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Brand	Unbranded/Generic
MPN	Does not apply
UPC	Does not apply
