From Us Cnc 3018 Woodworking Carving Engraving Machine Laser Machine Mill Pcb

US $135.00

Los Angeles, United States
Aug 30th

Open on mobile:
QR code

USA Stock & Located in USA & fast shipping Ship from USA Warehouse by UPS free VAT & free import duty fast shipping service ship to US Customer from US CNC 3018 Woodworking Carving Engraving Machine Laser Machine Mill PCB Parcel: 1 x 3018 GRBL DIY Mini CNC Laser machine kit (without laser) 1 x ER11 Collet 1 x GRBL Control Board 10 x 20°0.1mm drill bits Set of allen wrench 1 x power supply User manual & GRBL Software can download from CD Descriptions: CNC Router Mini 3018 GRBL Desktop Pcb Wood Engraving Milling Machine Introduction: Body used profiles and plastic, small size, light weight, USB interface, GRBL control system, learning, entry preferred. Can use carving knife, but also can use laser engraving. Can be engraved plastic, wood, acrylic, pvc, pcb, wood and the other similar material. Specification: Working area : 30x18x4.5cm Frame size : 40x33x24cm Spindle : 775 spindle motor (12-36V) 24V: 10000r/min Spindle Chuck: normal Step motor: Fuselage length 34MM,Current 1.33A, 12v.Torque 0.25N/M Power supply : 24V 5.6A Software: GRBL controller Support System: Windows XP / Win 7 / Win 8 / Win 10 / Linux Drill bits: tip 0.1mm ,20 degree , diameter3.175mm.the package include 10p Laser: Support 500mw 405nm 12v / 2500mw 450nm 12v / 5500mw 450nm 12v. 2. GRBL 1.1F USB port cnc engraving machine control board, 3 axis control Specification: Connection: USB (USB-CH340) Software: GRBL controller, UniversalGcodeSender Input voltage: 24VDC (12-24VDC) Stepper motor: support 24V 2A Spindle motor: support 24V 10A (supports PWM0%-100%) Master chip: atmel 328P (arduino nano) Spindle drive chip: MOSFET (recommendation 12~36V, current : within 10A ) Spindle PWM speed: Support Support stepper motor: 12V, maximum current of 2A or less is recommended within 1.5A and additional heat. (Any stepper motor 42, 57) Laser engraving: Support Power Interface: 5.5-2.5mm DC interface Support system: win-xp,win7,win8,win10 Advantage add the outer casing: mainly for the bare board of the control board, short circuit problem during use add the power button switch (this switch is the power supply control signal, there is no large current passing through the switch, do not worry about the switch size) Cancel the drive module, integrated imported stepper motor drive, with short circuit protection, no need to worry about module damage. And integrated heat dissipation aluminum alloy add the fan to force heat dissipation. add offline recognition to insert offline modules and computers at the same time. Offline will automatically identify if there is computer control. Enhanced spindle drive. Can support 20,000 rpm spindle. Support for larger power spindles Features: Small and practical, no problem for using on your desk. The control system is open source (technology that controls system is provided) for some players who like DIY. Desktop DIY mini CNC engraving machine for carving and more cost-effective than normal engraving machine. Support our professional English design software for Win 7, XP, Win 8, Win 10. 500mw / 2500mw / 5500mw optional laser module with heatsink, high laser engraving power and long working time. 180*100*45mm working area, Control Software: GRBL (include ER11 chuck). Aluminum alloy and nylon material with fine workmanship show excellence in quality. Very interesting to install and use, perfect gift for engraving DIY enthusiasts. Wide application: can be used for print, hand tools and industrial processing. Can use Laser (2-axis plane carving): Laser Interface: 12V, support PWN Laser Power: 500mw/2500mw/5500mw Control Software: laser GRBL Support File: G-code/picture Working Accuracy: 0.1mm Machinable Material: Wood, plastic, leather, paper, etc Main application: Can be engraved plastic, wood, acrylic, pvc, pcb, wood and the other similar material. Shipping Please open the package and check if there are some damages before sign,if there are some damages,please do not sign and contact us immediately. Payment Only accept paypal payment method. Payment must be made within 3 days. Problem&Feedback Please give us the opportunityto resolve any problem when you have,we concern your problem and we will try our best to resolve it. Pls contact us before you want to leave any negative feedback.

Condition:	New: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details. ...	Country/Region of Manufacture	China
Spindle	775 spindle motor(12-36V) 24V:10000r/min
Working area	30x18x4.5cm
MPN	Does Not Apply
Type	Desktop CNC Router
Model	3018+ER11
Drive	Stepper motor 34MM,Current 1.33A, 12v.Torque 0.25N/M
Collet	ER11 Collet
Port	USB port
CNC or Not	Also can work as cnc router
laser	Support laser
Power supply	24V 5.6A
Software	Grbl Control
Frame size	40x33x24cm
System requirements	windows XP SP3, win7, win8, win10. (32/64 can be
Brand	RATTMMOTOR
UPC	Does not apply
