Gw Instek Gag-810 Audio Generator, 10hz To 1mhz Frequency Range

US $1900

USA, United States
May 27th

Open on mobile:
QR code

GW Instek GAG-810 Audio Generator, 10Hz to 1MHz Frequency Range Item Description 10Hz to 1 MHz Frequency 0.02 Percent low sine wave distortion 6 Steps output attenuator External synchronization signal function Measures 130mm width by 210mm height by 292mm depth Features The GAG-810 provide a convenient solution for low frequency (less than 1 MHz) signal generation, specifically for audio bandwidth. Intuitive and simple panel interface provides quick frequency and amplitude adjustment, with dial/key shortcuts to different ranges. Square wave generation covers digital application in addition to the traditional analog using sine waves. Distortion is kept at minimum level, especially at the audible frequency range: 0.02 percent or less distortion factor for 500Hz to 20kHz. The external synchronization signal input helps collaborate with other measurement devices. Sine Wave Characteristic: 10Hz to 1 MHz, 5 Ranges - frequency range; Dial Scale frequency indicator; +/-3 percent + 1Hz (at x10, x100) frequency accuracy; 5 Vrms (600O load) output voltage; 10Hz to 1 MHz +/- 0.5dB(at 600 ohm load) frequency response. Square Wave: less than or equal to 10Vp-p (no load) output voltage; greater than or equal to 2 percent (at 1kHz, max output) overshoot; greater than 200nS rise and fall time; 50 percent+/-5 percent duty ratio. Ext. Synchronization: +/-1 percent/Vrms synchronizing range; 15V (DC + AC peak) max. allowable input; 150 killohm input impedance. Output: 600 ohm output impedance; 0, -10, -20, -30, -40, -50dB; 6 ranges (accuracy+/-1dB at 600 ohm load) output attenuator. Measures 130mm width by 210mm height by 292mm depth. Additional Information Manufacturer: GW Instek Shipping Weight: 730 Product Dimensions: Width: 10.70 Length: 13.50 Height: 8.00 Shipping Details Depending on your location and on package weight, items will be shipped by USPS or UPS. All stock is at our USA warehouses. Most orders ship within 24 hours of processing your payment unless stated differently. Check our feedback to see how our customers love the FAST shipping we offer! Shipping is always free! 30 Days Return & Refund Policy We provide a 30 days return/exchange policy for our products. The buyer can choose between a refund or an exchange to his/her product. In case of defectives found, only factory defects are accepted as the reason of return. The package of the returned item(s) must be completely intact, and all accessory(s) inside the package must be original and in perfect condition. We do not cover the postage costs for returned defective items. Items returned must be received within 30 days from purchase. No refund or replacement is issued after this period of time. Please allow up to 7 working days for your return to be processed after it is received by us. We are extremely fair, and in the rare event of something out of the ordinary happening, we will gladly work with you to find a solution. Our Guarantee Your satisfaction is guaranteed! We offer a 100% Satisfaction Guarantee on all sales. If you are not happy with your purchase for any reason, please contact us within seven days of receipt of your item, or email us to share your concerns. As mentioned before we are extremely fair and will happily work with you to find a solution to any problem. As you can tell from our feedback, pretty much every single one of our customers is a happy one. So in the rare case something does go wrong, before leaving a negative feedback, contact us so we can help you and make things right! About Us We sell on eBay since 2006. We are based in the USA and ship from our own warehouses. Our products are a 100% authentic and all brand new. We work with the biggest suppliers in the US to bring you the best quality items you can get! We guarantee to provide the best service you have ever seen before Please see our other items Automotive Baby Camera & Photo Clothing Electronics Health & Personal Care Home & Kitchen Home Improvement Kitchen & Dining Office Products Shoes Sports & Outdoors Toys & Games Feedback Profile Other Auctions
