Gw Instek Gfg-8020h Function Generator With 4 Digits Led Display, Ttl/cmos

US $370

USA, United States
May 27th

Open on mobile:
QR code

GW Instek GFG-8020H Function Generator with 4 Digits LED Display, TTL/CMOS Output, 0.2Hz to 2MHz Frequency Range Item Description Coarse and fine tuning Large 0.5" LED display; built-in 4 digits counter Variable DC offset control Output overload protection VCF Input function Features 2 MHz Function generator. The GFG-8020H function generator delivers one of the most economic and feature-rich solutions available in the 2 MHz frequency range. The GFG-8020H offers extra value with CMOS output, a built-in 4-digit counter, Coarse and Fine tuning with a 1000: 1 Tuning Range, and a digital LED display. Combined with functions, such as variable DC offset control, output overload protection, and VCF input, the GFG-8020H is suitable for the most demanding budgets in education or instrument testing. Frequency Range: 0.2Hz to 2 MHz, 7 ranges. Waveform: sine, triangle, square, TTL pulse and CMOS output. Internal frequency counter. Power Source, 100 MHz Bandwidth: AC100V/120V/220V/230V +/-10 percent, 50/60Hz. Accessories: 1 each of user manual, power cord and test lead GTL-101. Main Output: less than 20Vp-p (open circuit), less than 10Vp-p (into 50O load) amplitude; 50O +/- 10 percent impedance; -20dB +/- 1dB (at 1kHz) attenuator; greater than -10V to less than +10V (greater than -5V to less than +5V into 50O load) DC offset; 1:1 to 10:1 continuously adjustable duty control; Separate coarse and fine tuning frequency control. Sine Wave: greater than 1 percent (0.2Hz to 20kHz); greater than 2 percent (20kHz to 200kHz) distortion greater than 0.2dB (0.2Hz to 100kHz); greater than 1dB (100kHz to 2 MHz) flatness response. Triangle Wave: 98 percent, 0.2Hz to 100kHz; 95 percent, 100kHz to 2 MHz linear. Square Wave: greater than 2 percent, 0.2Hz to 100kHz symmetry; greater than 120nS rise / fall time. CMOS Output: 4Vpp +/- 1Vpp to 14.5Vpp +/- 0.5Vpp adjustable level; greater than 120nS rise / fall time. TTL Output: less than 3Vpp level; greater than 30nS rise / fall time. Frequency Counter: Internal mode; 0.2Hz to 2 MHz range; Time base accuracy +/- 1 count accuracy; Oscillation frequency 3.58 MHz, Temp. stability +/- 20ppm (23 degree C +/- 5 degree C) time base; 0.1Hz, 1Hz, 10Hz, 100Hz, 1kHz resolution. Measures 230mm width by 95mm height by 280mm depth. Additional Information Manufacturer: GW Instek Shipping Weight: 600 Product Dimensions: Width: 11.00 Length: 16.40 Height: 5.30 Shipping Details Depending on your location and on package weight, items will be shipped by USPS or UPS. All stock is at our USA warehouses. Most orders ship within 24 hours of processing your payment unless stated differently. Check our feedback to see how our customers love the FAST shipping we offer! Shipping is always free! 30 Days Return & Refund Policy We provide a 30 days return/exchange policy for our products. The buyer can choose between a refund or an exchange to his/her product. In case of defectives found, only factory defects are accepted as the reason of return. The package of the returned item(s) must be completely intact, and all accessory(s) inside the package must be original and in perfect condition. We do not cover the postage costs for returned defective items. Items returned must be received within 30 days from purchase. No refund or replacement is issued after this period of time. Please allow up to 7 working days for your return to be processed after it is received by us. We are extremely fair, and in the rare event of something out of the ordinary happening, we will gladly work with you to find a solution. Our Guarantee Your satisfaction is guaranteed! We offer a 100% Satisfaction Guarantee on all sales. If you are not happy with your purchase for any reason, please contact us within seven days of receipt of your item, or email us to share your concerns. As mentioned before we are extremely fair and will happily work with you to find a solution to any problem. As you can tell from our feedback, pretty much every single one of our customers is a happy one. So in the rare case something does go wrong, before leaving a negative feedback, contact us so we can help you and make things right! About Us We sell on eBay since 2006. We are based in the USA and ship from our own warehouses. Our products are a 100% authentic and all brand new. We work with the biggest suppliers in the US to bring you the best quality items you can get! We guarantee to provide the best service you have ever seen before Please see our other items Automotive Baby Camera & Photo Clothing Electronics Health & Personal Care Home & Kitchen Home Improvement Kitchen & Dining Office Products Shoes Sports & Outdoors Toys & Games Feedback Profile Other Auctions
