High Precision Electrolytic Capacitance And Inductance Lc Esr Meter

US $6100

Guangzhou , China
Jan 29th

Open on mobile:
QR code

High precision capacitance and inductance meter LC meter Description: 1, overview : LC200 is a small inductance capacitance meter can measure small capacitance and inductance , and electrolytic capacitors. The module is easy to use, by key operation , choose a different test methods . 2. product applications: ? measuring inductance ; ? measuring capacity ; ? measuring electrolytic power ; ? measuring ESR ( reference value , not on-line measurement ) 3 the technical parameters: 1. measuring small capacitance range 0.1pF ~ 1uF 2 large capacitance measurement range 0.1uF ~ 20mF 3 measuring inductance range 1uH ~ 10H 4 7 ~ 12 VDC operating voltage 5 working current <50 mA 6 Operating temperature -40 °C ~ 65 °C Celsius 7 Storage temperature -40 °C ~ 65 °C Celsius 8 Size 57 * 50 * 20 mm Length X Width X Height 4, the interface description and related operations P4 connector ( power supply ) VDD: positive power supply (7 ~ 12V) GND: power negative P5 interface ( output signals ) LC: take measure inductance or capacitance. GND: power negative . 5, KEYS Mes / Cal: calibration button. ( When measuring inductance measurement lines to short-circuit calibration ; small capacitance measurement , calibration measurement line to open . ) FUN: shows the measured parameters. ( Inductance and capacitance measurement is displayed when the measurement frequency. ) Package list: One Meter We only accept Paypal in Ebay. If you want to pay via other method please contact us. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to biding. Item will be shipped within 24 hours on payment received from Hong Kong using Airmail. Delivery time depends on destination and other factors, it may takes up to 30 business days. Optionally, Express Shipments with tracking service via EMS/DHL/UPS with a quoted delivery time of 5 to 7 business days is also available Here is the estimated time for your reference only: The delivery time may vary due to public holidays, countries, and customs etc. Thanks for your understanding! If the item is defective, please let me know as soon as possible after receive the items. The item will be returned its original condition, in order to get it refunded and replaced (please inquire us the returning address before you ship it back.) . Buyer is responsible for shipping costs when shipping products. You feedback is very important to us, please let us know before leaving any negative feedback or open any disputes on Paypal, please give me an opportunity to resolve any problems and we will try our best to satisfy your requirement. On Sep-21-14 at 09:25:40 PDT, seller added the following information:
