Rf Power Meter 0-500mhz -80 ~10 Dbm + 1602 Backlight Lcd

US $8000

Guangzhou , China
Jan 29th

Open on mobile:
QR code

RF power meter 0-500Mhz -80 ~10 dBm + 1602 backlight LCD Description: HP350 is a RF power meter, based on continuous compression technology fully monolithic 500 MHz demodulating logarithmic amplifier , the logarithmic amplifier provides 92 dB dynamic range, even at frequencies up to 100 MHz can still provide error is ± l dB dynamic range of 88 dB. The meter button to complete the operation, advantages: simple structure, easy to use, stable performance, reliable, high sensitivity and measurement speed and so on. Application: RF power measurement; Meter calibration Technical Data Sheet: Measuring power range: -80 ~ +10 dBm (external RF attenuator can be extended to 100dBm) Measuring Power Resolution: 0.1 dBm Measurement frequency range: 1 ~ 500 MHz Measuring power: 1nW ~ 2W Voltage: 7 ~ 12 VDC Working current: <50 mA Working temperature: -40 °C ~ 65 °C Storage temperature: -40 °C ~ 65 °C Size: 55mm * 45mm * 10 mm Interface display and operating instructions: Unit Description: dBm; Key Description: FUN: function keys; MODE: set changer interface; SEL: Self plus key or self minus key ; Display measurement data Interface display font: The first line "RF-POW -80.3 dBm" The second line "20uV 0nW" Note: the dBm value signal are shown, input voltage, the input power. Set the RF power attenuation values Interface display font: The first line "RF Attenuator" The second line "SUB 000dB" Key operation: FUN: function keys; (select plus or minus direction) as shown SUB Subtract, shows ADD a plus. (Long press FUN key to save the setting values in dB) SEL: Self plus key or minus key to Self; Note: External different RF power attenuator, set the corresponding attenuation coefficient reads the correct power parameters. Wiring: P1 connection definition: VDD :power supply positive (7V ~ 12V) GND: power supply negative P2 connection definition: FX :Unused RF:RF signal input GND: electronic scales power supply negative Package list: 1 X RF power meter 0-500Mhz -80 ~10 dBm We only accept Paypal in Ebay. If you want to pay via other method please contact us. Import duties, taxes and charges are not included in the item price or shipping charges. These charges are the buyer's responsibility. Please check with your country's customs office to determine what these additional costs will be prior to biding. Item will be shipped within 24 hours on payment received from Hong Kong using Airmail. Delivery time depends on destination and other factors, it may takes up to 30 business days. Optionally, Express Shipments with tracking service via EMS/DHL/UPS with a quoted delivery time of 5 to 7 business days is also available Here is the estimated time for your reference only: The delivery time may vary due to public holidays, countries, and customs etc. Thanks for your understanding! If the item is defective, please let me know as soon as possible after receive the items. The item will be returned its original condition, in order to get it refunded and replaced (please inquire us the returning address before you ship it back.) . Buyer is responsible for shipping costs when shipping products. You feedback is very important to us, please let us know before leaving any negative feedback or open any disputes on Paypal, please give me an opportunity to resolve any problems and we will try our best to satisfy your requirement. On Sep-21-14 at 09:25:40 PDT, seller added the following information:
