Hp/agilent 1660cs Logic Analyzer / Oscilloscope With Manual

US $895.00

San Diego, California, United States
Jan 29th

Open on mobile:
QR code

Hewlett Packard 1660CS Logic Analyzer / Oscilloscope Description: The 1660CS is 136 channel portable Logic Analyzer. The ability to connect to an Ethernet LAN provides an easy method of sharing data within the design team and provides remote access to the logic analyzer from a PC or workstation. A built-in 540 megabyte hard disk drive combined with the LAN connectivity now makes it possible to use the HP B3740A software analyzer for source line referencing; this is the ability to see correlated high-level C++ source code with the inverse assembled state listing. It adds two 1-GSA/s digitizing scope channels for viewing the analog behavior of your signals. Both channels capture non-repeating events simultaneously with 8K samples per channel. Characterize critical timing parameters with time interval measurements of better than 150 ps accuracy, or examine glitches in your system to determine if noise or loading is a problem. Features:136 state and timing channels.100 MHz state analysis with 2 state clocks/qualifiers.Integrated 2-channel 1-GSA/s Oscilloscope. Accessories: Comes with 346-page "User's Guide", 12-page "Datasheet", 106-page "LAN User's Guide" on a CD, and power cord. Size: 8 1/2 "H (11 1/2 " with Pouch) x 17 1/2 "W x 15"D, 30 Lbs without package. Condition: Comes with 8 Pods as in picture, Burnt screen but display looks clear when unit is on, Great shape, Very clean. Functional Test: Operational condition. Pictures: Front view, Back view, Pods view, Startup, System, Analyzer, Waveforms.
